e. To assure that the power unit is properly connected to the
frame ,you can try and lift the frame.
f. Connect the electrical connector coming from the frame to
the power unit Socket (See figure 4a) .
WARNING
After installing the frame onto the power unit and
locking it, Please check carefully that it is properly
positioned and secured.
2.2 Joining Tiller to Frame.
a. Place Tiller in front of the Frame. (See Fig. 5).
Kneel at the left side of the SUPERLIGHT holding the
left side of the Top Handle Bars of the Tiller with your
left hand. The Tiller should be vertical and slightly
inclined backward as shown in Figure 5.
b. With your right hand lift the Housing (at the front end of
the Frame) and place it above the (black) Tapered Pin
mounted on the Tiller.
c. Let the Housing slide down onto the black Tapered Pin
until you hear a “click”: at this time the Retaining Spring
should engage the Groove on the Tapered Pin thus
locking both sections to each other.
Figure 5
