CHAPTER 10 - SPECIFICATIONS *
DIMENSIONS: Metric (cm) U.S. (inches)
Width 62 24.4
Length with straight handlebars 113 44.5
Height of seat from floor 55-60 21.5-23.6
Ground clearance 7.5 3.0
WEIGHTS : Metric (kg) U.S. (lb.)
Tiller 6 13.2
Frame - complete 23 50.6
Frame (without power unit) 8.5 18.7
Power Unit 14.5 32
Batteries small (each) 2x6.7 2x14.7
Batteries large (each) 2x10.7 2x23.5
Seat +basket 9.6 +0.8 21+1.7
Total with small batteries 54 119
Total with large batteries 62 136.4
OPERATIONAL CHARACTERISTICS: Metric U.S.
Speed (Speed Selector switch)
Forward HIGH up to 8.0 km/h 5.0 mph
Forward LOW up to 4.5 km/h 2.8 mph
Reverse up to 4.5 km/h 2.8 mph
Maximum allowed load 110 kg 240 lbs.
Maximum rear basket load 10 kg 22 lbs.
Maximum traveling distance :
With battery 18 AH
With battery 26 AH
(with fully charged batteries user
weight 75 kg at level surface,
in high speed mode)
15-20 km
20-25 km
10-12.5 miles
12.5-37.5miles
Maximum downhill slope allowed 13 % 7.4 deg.
Maximum uphill climb (slope) allowed 13 % 7.4 deg.
Turning radius 70 cm 27.5 inch
Minimum safe turning radius 80 cm 31.5 inch
