4.4 Removal of Power Unit
a. Remove the Batteries. (As explained in 4.3).
b. Disconnect the electrical connector coming from the frame to
the power unit Socket (See Figure 22)
Figure 22
Figure 22a
c. Squeeze the rear knob at the right of the anti tip and pushed it
downward until locked again. (See Figure 22a)
d. Pull up the frame from the square bracket of the power unit
and lay it on the side (See Figure 23).
e. Now you can pick
up the power unit .
Figure 23
WARNING
The power unit weight approximately 14Kg (31 lbs)
Lift it only by loading your Knees .
Never lift it while loading your back
