User`s manual

________________________________________________________ 12
CHAPTER 3 - OPERATING INSTRUCTIONS
PLEASE READ THOROUGHLY CHAPTER 8 - “SAFETY
INSTRUCTIONS” - BEFORE DRIVING THE SUPERLIGHT.
Please charge your battery before first use (ca. 6 hours)
3.1 Mount the SUPERLIGHT, insert the Key into the Slot and turn
it clockwise
to the (marked) ON position. The Key will remain
in this position. Panel On Light should come ON.(See
Figure 14).
3.2 You can drive forward by gently squeezing the Right Hand
Operating Lever. You can drive reverse by gently
squeezing
the Left Hand Operating Lever.
The speed
of the SUPERLIGHT is proportional to the
deflection of the Lever
s; the more you squeeze the
faster you go (either direction).
3.3 TO STOP
: Release the Lever - it returns automatically to its
center (neutral) position and the SUPERLIGHT stops.
Note
: For your safety and comfort the following features are
part of the normal operating sequence;
- Slight delay after you squeeze the Lever before the motor
is engaged-
- When squeezing or releasing the Lever you should hear a
“click” indicating that the Electromagnetic Brake is
activated.
3.4 The SUPERLIGHT has 2 speed modes ; Low / High
a. In the High speed mode (marked by the “hare
” symbol next to
the Speed Selector switch) the maximum attainable speed is
7.5 km/h (4.6 mph) When selector is in High Speed Mode –
Green light of switch is ON. (See Fig. 11).
b. In the Low speed mode (marked by the “turtle
” symbol next to
the Speed Selector switch ) the maximum attainable speed is
4.5 km/h (2.8 mph).*
* When selector is in Low Speed Mode – Green light of switch
is OFF. (See Fig. 15).
