Antennas

You must provide 6 dual-band 5 dBi articulated indoor antennas for the AP245X. You can order

the following antenna kits from Aerohive:

SKU Description

AH-ACC-ANT-DB-5

One dual band RP-SMAfemale indoor 5 dBi articulated

antenna for the AP245X.

AH-ACC-DB-5-ANT-KIT

AP245X articulated indoor antenna kit (six dual band 5 dBi

antennas).

AH-ACC-120-ANT-KIT

120 degree dual-band 5 dBi sector antenna for AP245X with

three RP-SMA connectors. Kit includes three 2.5" (75 cm) coaxial

cables and mounting assembly.

AH-ACC-60-ANT-KIT

60 degree dual-band (5.5 dBi/6 dBi for 2.4 GHz/5 GHz) sector

antenna for AP245X with three RP-SMA connectors. Kit includes

three 2.5" (75 cm) coaxial cables and mounting assembly.

Locking Slot

When mounting the AP on a ceiling track or flat surface, you can secure it to the track using a

Kensington ® lock in the lock slot or using a security bracket (shipped separately). See "Securing

the AP245X".

Hardware Specifications

The following specifications describe the physical features and hardware components, PoE electrical

requirements, and the temperature and humidity ranges in which the devices can operate.

Device Specifications

• Chassis dimensions: 7.25" W x 2.12" H x 7.25" D (184 mm W x 54 mm H x 184 mm D)

• Weight: 1.6 lb (0.73 kg)

• Six external dual band antennas, and one internal BLE antenna

• One RJ45 Console port (9600 bits per second, 8 data bits, no parity, 1 stop bit, no fl

control)

• Eth0 Ethernet port: autosensing 10/100/1000Base-T/TX Mbps, with IEEE 802.3af- or 802.3at-

compliant PoE

• Eth1 Ethernet port: autosensing 10/100/1000Base-T/TX Mbps
