Model: AP904-SL Series
4” Duct
Static Pressure (inches w.g.)
0.1
0.25
Air Volume (CFM)
90
73
Noise (sones)
0.3
n/a
Power Consumption (Watts)
33
32.3
Energy Efficiency (CFM/Watts)
2.7
2. 2
Current (AMPS)
0.4
0.36
Grille Dimensions
13 3/8’ x 13 3/8”
Model
Qty
Project
Location
Architect
Engineer
Contractor
Submitted by
Date
Specifications
AP 904-SL SERIES
Slim Fit Bathroom Fan with 10W 4000K LED Light
ETL Listed for installation over tub/shower enclosure with
GFCI circuit wiring.
Description: Super quiet slim fit bathroom fan with 10W 4000K
1150 Lumens dimmable LED light Engineered for continuous
run Ceiling mount Suitable for new construction or
remodeling HVI certified ETL listed for use in insulated
ceilings (Type I.C.).
Motor/Blower: Permanently lubricated enclosed condenser
motor engineered for continuous energy efficient operation;
power rating 120v/60Hz; motor equipped with thermal shut off.
Housing: Rugged 26 GA galvanized steel; detachable 4 and 6”
duct connector with built-in back draft dampener; 2 anti-vibration
hangar bar brackets adjustable to 24” span included; designed for
ceilings with a minimum of 6” clearance.
Grille: Contemporary design; low maintenance, wipe clean UV
inhibiting polymeric resin; attaches to housing with torsion
springs.
Finishes: White (W); Satin Nickel (SN); Oil Rubbed Bronze
(OR).
Light: 10W 4000K 1150 Lumens dimmable LED light
Installation: Must be installed by a licensed professional.
Complete installation instructions included.
Warranty: 6 Years
Architect’s Specifications: Ventilation fan will be ceiling mount
and no more than 0.3 sones at 90 CFM as certified by HVI at 0.1
Ps (inches water gauge). Power consumption shall be no greater
than 33 watts with an efficiency rating of no less than 2.7
CFM/watt. Light shall be 10W 4000K dimmable LED light. The
motor will be permanently lubricated, engineered for continuous
operation. Duct diameter will be 4” or 6” round. Fan shall be
ETL/cETL listed for tub/shower enclosure when used with
GFCI branch circuit wiring and shall be ETL/cETL listed for use
in insulated ceiling (Type I.C.).
Aero Pure, LLC 1006 Bankton Cir cle Ste B Hanahan, SC 29410 843.377.8642
www. aer opur efa ns.com
