BMS - pCO5 1309 5806600_00

WHOLE VARIABLES

R (read) = Command code Modbus =3

R/W (read/write) = Command code Modbus = 6

Modbus

address

(BMS 1)

AerWeb300

address

(BMS2)

CAREL

Add.

Description

Unit of

meas-

urement

Min Max R/W

209 5002 1 System On/Off Mode (1=ON,2=Set2,3=TIME SLOTS) --- 1 3 R/W

210 5003 2 Recovery On/Off Mode (1=ON,2=Set2,3=TIME SLOTS) --- 1 3 R/W

211 5004 3

Summer winter selection (0=SUMMER,1=WINTER,2=By

External T.,3=By DIN,4=By BMS, 5=By Calendar)

--- 0 5 R/W

212 5005 4

213 5006 5

214 5007 6 System active power (0...100) % 0 100 R

215 5008 7 Recovery active power (0...100) % 0 100 R

216 5009 8 Top part timer, system 1 pumps --- 0 999 R

217 5010 9 Bottom part timer, system 1 pumps h 0 999 R

218 5011 10 Top part timer, system 2 pumps --- 0 999 R

219 5012 11 Bottom part timer, system 2 pumps --- 0 999 R

220 5013 12 Top bottom timer, circ.1 comp.1 --- 0 999 R

221 5014 13 Bottom part timer, circ.1 comp.1 h 0 999 R

222 5015 14 Top part timer, circ.1 comp.2 --- 0 999 R

223 5016 15 Bottom part timer, circ.1 comp.2 h 0 999 R

224 5017 16 Top part timer, circ.1 comp.3 --- 0 999 R

225 5018 17 Bottom part timer, circ.1 comp.3 h 0 999 R

226 5019 18 Top part timer, circ.2 comp.1 --- 0 999 R

227 5020 19 Bottom part timer, circ.2 comp.1 h 0 999 R

228 5021 20 Top part timer, circ.2 comp.2 --- 0 999 R

229 5022 21 Bottom part timer, circ.2 comp.2 h 0 999 R

230 5023 22 Top part timer, circ.2 comp.3 --- 0 999 R

231 5024 23 Bottom part timer, circ.2 comp.3 h 0 999 R

232 5025 24

233 5026 25

234 5027 26 Fan speed 1 (0..100%) % 0 100.0 R

235 5028 27 Fan speed 2 (0..100%) % 0 100.0 R

236 5029 28 Fan speed 3 (0..100%) % 0 100.0 R

237 5030 29 System side power request (0...100) % 0 100.0 R

238 5031 30 Domestic side power request (0...100) % 0 100.0 R

239 5032 31 Top bottom timer, recovery 1 pumps --- 0 999 R

240 5033 32 Bottom part timer, recovery 1 pumps h 0 999 R

241 5034 33 Top part timer, recovery pumps 2 --- 0 999 R

242 5035 34 Bottom part timer, recovery 2 pumps h 0 999 R

243 5036 35 Upper part peak counter, system 1 pump --- 0 999 R

244 5037 36 Lower part peak counter, system 1 pump --- 0 999 R

245 5038 37 Upper part peak counter, system 2 pump --- 0 999 R

246 5039 38 Lower part peak counter, system 2 pump --- 0 999 R

247 5040 39 Upper part peak counter, recovery 1 pump --- 0 999 R

248 5041 40 Lower part peak counter, recovery 1 pump --- 0 999 R

249 5042 41 Upper part peak counter, recovery 2 pump --- 0 999 R

250 5043 42 Lower part peak counter, recovery 2 pump --- 0 999 R

251 5044 43 Upper part peak counter, circuit 1 CP1 --- 0 999 R

252 5045 44 Lower part peak counter, circuit 1 CP1 --- 0 999 R
