Z-Wave products are supposed to work out of the box after inclusion, however certain configuration can adapt the function better

to user needs or unlock further enhanced features.

IMPORTANT: Controllers may only allow configuring signed values. In order to set values in the range 128 … 255 the value sent in

the application shall be the desired value minus 256. For example: to set a parameter to 200 it may be needed to set a value of

200 minus 256 = minus 56. In case of a two byte value the same logic applies: Values greater than 32768 may needed to be given

as negative values too.

Blinking Behavior (Parameter Number 2, Parameter Size 2) This is a double byte value. The LSB defines the total

time the device need to blink. The value if set in seconds. The MSB defines the on/off interval of the blinking. The unit is 0.1 s.

Value Description

1 — 255 This is a double byte value. The LSB defines the total time the device need to blink. The value if set in seconds. The

MSB defines the on/off interval of the blinking. The unit is 0.1 s.

Current Overload Protection (Parameter Number 3, Parameter Size 1) Load will be closed when the Current

overrun (US: 15.5A, other country: 16.2A) and the time more than 2 minutes (0=disabled, 1=enabled).

Value Description

0 Active Overload Protection (Default)

1 Deactivate Overload Protection

Output Load Status (Parameter Number 20, Parameter Size 1) Configure the output load status after re‐power

on.

Value Description

0 last status (Default)

1 always on

2 always off

Notification on Status Change (Parameter Number 80, Parameter Size 1) Defines the automated status

notification of an associated device when status changes (0=nothing, 1=hail CC, 2=basic CC report).

Value Description

0 nothing (Default)

1 hail

2 basic CC report

Configure the state of red LED (Parameter Number 81, Parameter Size 1)

Value Description

0 The LED will follow the status (on/off) of its load. (Default)

1 When the state of Switch’s load changed, The LED will follow the status (on/off) of its load, but the red LED will turn off

after 5 seconds if there is no any switch action.

Enables/disables parameter 91/92 (Parameter Number 90, Parameter Size 1)
