Model: DG458 Quad Input 5.8GHz Wireless AV Sender System m? o e ro eiv n 1 ec ha R e t al ils or tion deta o m i or t t dd u f mi X A i.e ns R ae ra 45 w. ot G w tt D w an d a it: W nee Vis u Yo WATCH A VIDEO INSTALLATION & & TROUBLESHOOTING TROUBLESHOOTING GUIDE GUIDE Available Available online online at: at: www.aei.eu/video www.aei.
DG458 - DigiSender ZX7 - Quad Input 5.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Introduction Congratulations on purchasing the DigiSender® ZX7 - Quad Input 5.8GHz Wireless AV Sender System. This product represents state of the art wireless audio and video technology and the most advanced Infra-Red relay technology at exceptional value for money. You can now enjoy DVD quality video and Hi-Fi stereo sound from your Satellite, Cable, Freeview, DVD or VCR in another room in your home.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Installing your DigiSender® Step 1 - Unpack your DigiSender® Aux 2 Input 4 Aux 1 Input 3 DigiConnector™ 2 Input 2 DigiConnector™ 1 Input 1 POWER All DigiSender® orders are computer weight checked when packed. However, it is a good idea to check all kit contents are present before proceeding with the installation.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Installing your DigiSender® Step 2 - Install the Transmitter The Transmitter will send the audio and video from up to four connected sources (your Satellite receiver and DVD Player for example) to the Receiver, located in another room in your home. 4. 1. 4. 2. Connect DigiConnector™ 1 to your Satellite, Cable Obis aut et pe nisin pre nonectius ipis ipicit eum or Freeview box.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Installing your DigiSender® continued... Note: Try to avoid positioning the Transmitter directly on top of other electrical devices as this could lead to a poor picture. 5. 6 Connect the Power Supply Unit (PSU) to the socket labelled ‘PSU’ on the rear of the Transmitter. Connect the Power Supply Unit (PSU) to an available mains socket.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Installing your DigiSender® Step 3 - Install the IR Systeme Technik Remote Relay Kit™ Once set up correctly, the IR Systeme Technik™ Remote Relay Kit will enable you to control your source equipment from the receiving location in your home. Because everyone’s set up is different there are many ways you can install the IR Systeme Technik™ Remote Relay Kit and the various included accessories will help you in setting it up correctly.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Installing your DigiSender® Step 4 - Install the Receiver The Receiver will pick up the signals being sent by your Transmitter and output them to a connected TV. 1. 3. 4. Locate a vacant SCART socket on the back of your receiving TV and insert the DigiSender® SCART cable.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Using your DigiSender® Standard Operation The steps below should be followed every time you use the DigiSender®. 1. 2. Switch on the source equipment (Satellite, Freeview, DVD, VCR, etc.). Turn on the Transmitter and Receiver by pushing the Power button on the front of the units. The Power LED will change from red to green to indicate the unit is switched on. Alternatively press the Power button on the DigiSender® Remote Control. 3.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Using your DigiSender® Advanced Functions Changing the Audio/Video Channel The DigiSender® ZX7 features 4 Audio/Video Channels. Each of these Audio/Video Channels slightly changes the frequency on which the DigiSender® ZX7 operates. Because the Audio/Video Channel switch allows you to ‘fine tune’ the frequency on which your DigiSender® ZX7 operates, it is possible to overcome most interference and reception troubles that may occur.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Using your DigiSender® The DigiSender® Remote Control 1. POWER The POWER button will turn your DigiSender® Transmitter or Receiver On or Off. 2. Input 1 The Input 1 button will select Input 1 on the Transmitter and Receiver. Input 1 will be what ever source equipment is connected to DigiConnector™ 1. For example, your Satellite, Cable or Freeview box. 3. Input 2 The Input 2 button will select Input 2 on the Transmitter and Receiver.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Troubleshooting Picture Problems What do you see on the second TV? The picture is present but poor quality... POOR RANGE 1. The picture & sound quality is affected by the Transmitter and Receiver’s location. Try positioning them in different locations. The Transmitter and Receiver should be connected to a mains extension lead that can be moved. 2.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Troubleshooting What do you see on the second TV? I see a snowstorm or blue screen... Switch OFF your DigiSender® RECEIVER. What do you now see on the second TV? I now see a black screen... NOT RECEIVING SIGNAL 1. Switch the DigiSender® Receiver back on. 2. Ensure the DigiSender® Transmitter is switched on. 3.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Troubleshooting Sound Problems I can see the picture but can’t hear anything. 1. Disconnect both the Transmitter AND Receiver SCART cables. Reconnect the cables ensuring they are pushed into the sockets firmly. 2. If you are using a home cinema DVD player with surround sound, please ensure the analogue audio output on SCART is switched on. The sound is distorted.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Troubleshooting Remote Relay Problems If you have any difficulty operating your source equipment remote control in your second room please follow the advice below below: 1. Ensure the IR Emitter is connected to the socket labelled ‘IR’ on the Transmitter. 2. Ensure you are using the correct remote control in the second room. For instance, if you are trying to control your Satellite box you will need to use the Satellite remote control.
DG458 - DigiSender ZX7 - Quad Input 5.8GHz Wireless AV Sender System Troubleshooting Technical Support & Accessories Technical Support AEI Security & Communications Ltd is dedicated to providing our customers with first class customer care and technical support. 1. Website Free technical advice is available online 24/7 at our dedicated support web site: www.aei.eu 2. Online Videos Watch online Installation and Troubleshooting Video Guides at: www.aei.eu/video 3.
DG458 - DigiSender ZX7 - Quad Input 5.
DG458 - DigiSender ZX7 - Quad Input 5.
D E CL AR AT I O N O F CO NF O R MI T Y 01022007/01/DG-DV-DX We, AEI Security & Communications Ltd. Weslake Industrial Park, Harbour Road, Rye, East Sussex, TN31 7TE, United Kingdom declare under our sole responsibility that the products bearing the series code prefixed: DGx, DVx, DXx (x refers to the specific model number) are in conformity with the essential requirements of Directive 1995/5/EC.
SPECIFICATIONS Transmitter Inputs Receiver Outputs Audio/Video Frequency Remote Control Compatiblity Video Input Level Video Input Colour Audio Input Level Audio Bandwidth Range Power Dimensions Weight 2x DigiConnector™ SCART, 2x A/V 1x SCART, 1x Composite 5.7250GHz ~ 5.8750GHz RC5, RC6, IrDA 1V Peak-Peak 75Ω PAL (Phase Alternate Line) 1.0v PP (Mod 1KHz, Dev 15KHz) 20Hz - 22KHz (-3dB) 100m (Free-Air), 40m (Nominal) 12V DC, 300mA L: 100mm, W: 160mm, H: 40mm 0.
