PCM-9584 User Manual 54
Chapter 7 LAN Configuration
7.1 Introduction
The PCM-9584 is equipped with a high-performance 32-bit Ethernet
chipset which is fully compliant with IEEE 802.3 100 Mbps CSMA/CD
standards. It is supported by major network operating systems. It is also
both 100Base-T and 10Base-T compatible.
7.2 Features
• Intel 82551 10/100Base-T Ethernet LAN controller
• Optional Intel 82541 10/100/1000 Base-T Ethernet LAN controller
• Supports Wake-on-LAN remote control function.
• PCI Bus Master complies with PCI Rev. 2.2
• Complies with 100Base-TX, and 10Base-T applications.
• Single RJ-45 connector gives auto-detection of 10 Mbps or 100 Mbps
network data transfer rates and connected cable types.
• Enhancements on ACPI & APM.
• Complies with PCI Bus Power Management Interface Rev. 1.1,
• ACPI Rev. 2.0, and Device Class Power Management Rev. 1.0.
7.3 Installation of Ethernet Driver
Please read the instructions in this chapter carefully before you attempt
installation. The drivers for the PCM-9584 board are located on the
audio driver CD. Run the supplied SETUP program to install the drivers;
don’t copy the files manually.
Note:
1. Before trying to install the driver, go to Chapter 3 to use the "Chipset Soft-
ware Installation Utility " first.
2. The files on the software installation diskette are compressed. Do not
attempt to install the drivers by copying the files manually. You must use the
supplied SETUP program to install the drivers.
