PCM-9584 User Manual 24
Chapter 3 Software Configuration
3.1 Introduction
The PCM-9584 system BIOS and custom drivers are located in a 256 Kb
flash ROM device designated U6. A single flash chip holds the system
BIOS, VGA BIOS and network Boot ROM image. The display can be
configured via CMOS settings. This method minimizes the number of
chips and difficulty of configuration. To set different types of LCD pan-
els, please choose “panel type” from the “integrated peripherals” menu in
CMOS setup.
3.2 Connections to Three Standard LCDs
The following tables illustrate typical LCD connection pinouts for the
PCM-9584.
3.2.1 LG LM150X06 (1024x768(16 colors) LVDS LCD)
Table 3.1: Connections to LCD/ Flat Panel (CN16)
LCD Connector Flat Panel Connector
Unipac-UB104S01 DF-13 40P
Pin Signal Pin Signal
1Vcc 13.3V
2Vcc 23.3V
3GND 3GND
4GND 4GND
5 RxIN0- 7 LVDS_YAM0R
6 RxIN0+ 9 LVDS_YAP0R
7GND 11GND
8 RxIN1- 13 LVDS_YAM1R
9 RxIN1+ 15 LVDS_YAP1R
10 GND 17 GND
11 RxIN2- 19 LVDS_YAM2R
12 RxIN2+ 21 LVDS_YAP2R
13 GND 23 GND
14 CKIN- 25 LVDS-CLKAMR
15 CKIN+ 27 LVDS-CLKAPR
