PCM-9584 Onboard Intel® Pentium M EBX SBC with Audio, VGA/2 LVDS and LAN User Manual
Copyright This document is copyrighted, © 2007. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the original manufacturer. Information provided in this manual is intended to be accurate and reliable.
Packing List Before you begin installing your card, please make sure that the following materials have been shipped: • 1 PCM-9584 all-in-one single board computer • 1 CD disk for utility and drivers • 1 startup manual • 1 Mini Jumper*10 PCS Package (p/n: 9689000002) • 1 ATX power cable (p/n:1700001112) If any of these items are missing or damaged, contact your distributor or sales representative immediately. Model No.
FCC This device complies with the requirements in part 15 of the FCC rules: Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Additional Information and Assistance 1. Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
PCM-9584 User Manual vi
Contents Chapter 1 Introduction ......................................................2 1.1 1.2 1.3 1.4 Introduction ....................................................................... 2 Features ............................................................................. 2 Specifications .................................................................... 3 Board layout: dimensions.................................................. 5 Figure 1.1:Board layout: dimensions (component side). 5 Figure 1.
2.17 2.18 TV-out interface .............................................................. 21 Ethernet configuration (CN6, CN10) .............................. 21 2.18.1 100Base-T connector (CN6, PCM-9584) ..................... 21 2.18.2 Network boot ................................................................ 21 2.19 2.20 2.21 2.22 2.23 Chapter USB connectors (CN12,CN13,CN14) ............................ 21 LCD Backlight connector (CN23) ..................................
5.1.2 5.1.3 5.1.4 5.2 Installation of the PCI Graphic driver ............................. 43 5.2.1 5.3 Chapter Installation for Windows 98/ME/2000/XP ................... 43 Further Information ......................................................... 46 6 Audio Setup.....................................................48 6.1 6.2 Introduction ..................................................................... 48 Driver installation............................................................ 48 6.
Table B.23:CN25 48bit LVDS Connector.................... 88 Table B.24:CN26 CRT connector ................................ 90 Table B.25:CN27 SYS FAN connector........................ 91 Table B.26:CN28 Inverter connector............................ 91 Table B.27:CN29 SPK-OUT connector ....................... 92 Table B.28:CN30 Compack II W/Ejector..................... 92 Table B.29:CN31 MINI PCI connector........................ 94 Table B.30:CN32 MIO USB connector........................
CHAPTER 1 General Information This chapter gives background information on the PCM-9584.
Chapter 1 Introduction 1.1 Introduction The PCM-9584 series is a EBX SBC (Single Board Computer) designed with powerful Intel Pentium M or Celeron M processors, with Intel 915GME and ICH6M chipset, which supports enhanced Intel "SpeedStep" technology and dynamic video memory technology for maximum performance, PCM-9584 also supports two x 200-pin SODIMM Double Data Rate (DDR2) with ECC DDR memory up to 2 GB.
1.3 Specifications Standard SBC Functions • CPU: Embedded Intel® Pentium® M (Banias/Dothan) and Celeron® M processor supported • BIOS: AWARD® 512K byte Flash BIOS • System memory: 2 x 200-pin SODIMM sockets, Double Data Rate (DDR2)128 MB to 2 GB, accepts 128/256/512/1024 MB DDR2 up to 400/533 DRAM. • System chipset:Intel 915GME GMCH/ICH6M Chipset • 2nd cache memory: Depends on CPU from 512 KB to 2 MB • Enhanced IDE interface: One Enhanced IDE interface supports 2 IDE devices.
Solid State Disk • CFC type I/II (shared 2nd IDE Channel)/uDOC (option) VGA/LCD Interface • Chipset: Intel 915GME • Frame buffer: Optimized Shared Memory Architecture, supports up to 128MB frame buffer using system memory • Interface: Dual channel LVDS panel supports up to UXGA panel resolution • Display mode: CRT Modes: pixel resolution up to 1600 x 1200 at 85Hz and 2048 x 1536 at 75-Hz • LCD mode: Dual channel LVDS panel support up to UXGA panel resolution with frequency range from 25-MHz to 112-MHz • LVD
(Pentium M with 2.0GHz) Max(HCT):2.43A @ 5V, 1.65A @ 12V Suspend: 1.87A @ 5V, 0.75A @ 12V • Operating temperature:0 ~ 60° C (32~140° F) • Operating Humidity:0% ~ 90% Relative Humidity, non-condensing • Weight: 0.85 kg (weight of total package) 146.05 142.62 140.97 198.17 199.44 184.24 188.73 174.08 138.26 141.46 141.61 129.27 132.89 117.08 118.16 90.98 94.54 71.81 72.95 73.96 4.62 5.13 41.33 1.4 Board layout: dimensions H2 H1 143.08 140.97 131.79 127.51 123.83 120.14 116.84 113.28 113.
84.92 114.82 146.05 114.52 113.98 79.82 20.28 0.00 141.92 150.67 203.20 0.00 Figure 1.2: Board layout: dimensions (solder side) Note: In Power off status to clear CMOS, auto boot up will appear when power on.
CHAPTER 2 Installation This chapter explains the setup procedures of PCM-9584 hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installation procedure.
Chapter 2 Installation 2.1 Jumpers The PCM-9584 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers Label Function JP1 PCIVIO POWER Select JP2 CLEAR CMOS JP3 COM2 RS232/422/485 Select JP4 VDD_LVDS_PANEL POWER Select JP5 VDD_FP POWER Select JP6 +VCCA_PROC_IN Select JP7 Compact Flash Master/Slave Select J8 CPU Dothan/Banias Select J9 ATX/AT Power Select 2.1.
JP3 COM2 RS232/422/485 Select (5-6).
JP4 VDD_LVDS_PANEL POWER Select 1-2 3.3V 2-3 5V 1 2 3 JP5 1 2 3 VDD_FP POWER Select (1-2) 3.
J8 CPU Dothan/Banias Select (1-2).(5-6) Dothan (1-2).(3-4) Banias J9 ATX/AT Power Select (1-2) ATX Power (2-3) AT Power 1 2 3 1 2 3 2.2 Connectors Onboard connectors link the PCM-9584 to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the function of each of the board’s connectors. Table 2.
CN18 IDE connector CN19 COM1/2/3/4 connector CN20 PC104+ connector CN21 AUDIO connector CN22 LVDS connector CN23 LCD Backlight CN24 CD-IN connector CN25 48bit LVDS connector CN26 CRT connector CN27 SYS FAN connector CN28 Inverter connector CN29 SPK-OUT connector CN30 Compact II W/Ejector CN31 MINI PCI connector CN32 MIO USB connector PCM-9584 User Manual 12
CN7 CN5 CN14 CN2 CN12 CN4 CN13 CN15 J1 PCI1 J6 CN11 CN8 2.3 Locating jumpers and Connectors H2 H1 CN6 CN1 C45 CN10 CN16 CN17 J2 CN18 CN19 J3 DIMM1 J7 J4 CN21 CN29 CN24 CN26 J2 CN20 CN28 CN23 J5 CN22 CN25 H4 CN27 H3 Figure 2.
CN32 CN31 CN30 Figure 2.
2.4 Setting Jumpers You may configure your card to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To “close” a jumper, you connect the pins with the clip. To “open” a jumper, you remove the clip. Sometimes a jumper will have three pins, labeled 1, 2 and 3.
2.5 Clear CMOS (JP2) Warning! To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS.” Before turning on the power supply, set the jumper back to “3.0 V Battery On.” This jumper is used to erase CMOS data and reset system BIOS information. The procedure for clearing CMOS is: 1. Turn off the system. 2. Push JP2 3. Turn on the system. The BIOS is now reset to its default setting 2.6 Installing DIMMs The procedure for installing DIMMs is described below.
2.7 IDE, CDROM hard drive connector (CN18) The PCM-9584 provides 1 IDE channel which you can attach up to two Enhanced Integrated Device Electronics hard disk drives or CDROM to the PCM-9584’s internal controller. The PCM-9584's IDE controller uses a PCI interface. This advanced IDE controller supports faster data transfer, PIO mode 3, mode 4 and UDMA/100. The secondary channel supports UDMA/33 only. 2.7.1 Connecting the hard drive Connecting drives is done in a daisy-chain fashion.
2.9 Parallel port connector (CN17) Normally, the parallel port is used to connect the card to a printer. The PCM-9584 includes a multi-mode (ECP/EPP/SPP) parallel port accessed via CN17 and a 26-pin flat-cable connector. You will need an adapter cable if you use a traditional DB-25 connector. The adapter cable has a 26-pin connector on one end, and a DB-25 connector on the other. The parallel port is designated as LPT1, and can be disabled or changed to LPT2 or LPT3 in the system BIOS setup.
2.12 Power connectors (CN11,CN1) 2.12.1 ATX/ AT power connector (CN1) Supplies main power to the PCM-9584 (+5V) and to devices that require it. Please refer to 2.1.1 Jumpers setting J9 for ATX/AT Power mode select. 2.12.2 CPU -12V and -5V connector (CN4) Supplies -5V/-12V for ISA/PCI device. 2.13 Power ON/OFF switch con. pin 11-12 of CN5 2.13.1 ATX feature (CN5) & soft power switch (CN5) The PCM-9584 can support an advanced soft power switch function, if an ATX power supply is used.
audio signal into the audio controller. The audio cable of your CD-ROM drive will be used to connect to CN24. 2.15 COM port connector (CN19) The PCM-9584 provides four RS-232 serial ports (COM1,3,4:RS-232, COM2: RS-232/422/485) in one COM port connector. The COM port connector is a 40-pin, DF13A-40DP-1.25V (Hirose Electric Co., Ltd.). It provides connections for serial devices (a mouse, etc.) or a communication network. You can find the pin assignments for the COM port connector in Appendix C.
2.17 TV-out interface PCM-9584 A2 TV out function is disabled because Micro vision license issue on Intel 915GME. 2.18 Ethernet configuration (CN6, CN10) 2.18.1 100Base-T connector (CN6, PCM-9584) 10/100/1000 Base-T connects to the PCM-9584FG via an adapter cable to a 10-pin polarized header. 2.18.2 Network boot The Network Boot feature can be utilized by incorporating the Boot ROM image files for the appropriate network operating system.
2.22 DI/O connector (CN16) The PCM-9584 supports DIO interface by CN16, which is a 7 x 2 dual line pin header, supply 8 general purpose input or output ports. 2.23 CPU Fan power supply connector (CN11) Provides power supply +12V to CPU cooling fan, and fan speed detects signal input.
CHAPTER 3 Software Configuration This chapter details the software configuration information. It shows you how to configure the card to match your application requirements. The AWARD System BIOS is covered in Chapter 4. Sections include: • Introduction • Connections for standard LCDs • Ethernet interface configuration.
Chapter 3 Software Configuration 3.1 Introduction The PCM-9584 system BIOS and custom drivers are located in a 256 Kb flash ROM device designated U6. A single flash chip holds the system BIOS, VGA BIOS and network Boot ROM image. The display can be configured via CMOS settings. This method minimizes the number of chips and difficulty of configuration. To set different types of LCD panels, please choose “panel type” from the “integrated peripherals” menu in CMOS setup. 3.
Table 3.
PCM-9584 User Manual 26
CHAPTER 4 Chapter 4 Ducks that Need Love! Award BIOS Setup This chapter describes how to set BIOS configuration data.
Chapter 4 Award BIOS Setup 4.1 System test and initialization These routines test and initialize board hardware. If the routines encounter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal. The system can usually continue the boot up sequence with non-fatal errors.
4.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 4.2.1 Entering setup Power on the computer and press immediately. This will allow you to enter Setup. Figure 4.
4.2.2 Standard CMOS Features setup When you choose the Standard CMOS Features option from the Initial Setup Screen menu, the screen shown below is displayed. This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is highlighted, on-line help information is displayed in the left bottom of the Menu screen. Figure 4.
4.2.3 Advanced BIOS Features setup By choosing the Advanced BIOS Features Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9584 Series. Figure 4.3: Advanced BIOS Features setup 4.2.4 Advanced Chipset Features setup By choosing the Advanced Chipset Features option from the Initial Setup Screen menu, the screen below is displayed.
4.2.5 Integrated Peripherals Choosing the Integrated Peripherals option from the Initial Setup Screen menu should produce the screen below. Here we see the manufacturer’s default values for the PCM-9584 Series. Figure 4.5: Integrated Peripherals 4.2.6 Power Management Setup By choosing the Power Management Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9584 Series. Figure 4.
4.2.7 PnP/PCI Configurations By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9584 Series. Figure 4.7: PnP/PCI Configurations 4.2.8 PC Health Status The PC Health Status option displays information such as CPU and motherboard temperatures, fan speeds, and core voltage. Figure 4.
4.2.9 Frequency/Voltage Control By choosing the Frequency/Voltage Control option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCM-9584 Figure 4.9: Frequency/Voltage Control Caution Incorrect settings in Frequency/Voltage Control may damage the system CPU, video adapter, or other hardware.
4.2.10 Load Optimized Defaults Figure 4.10: Load Optimized Defaults Load Optimized Defaults loads the default system values directly from ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load automatically when you turn the PCM-9584 Series system on. 4.2.
To Establish Password 1. Choose the Set Password option from the CMOS Setup Utility main menu and press . 2. When you see “Enter Password,” enter the desired password and press . 3. At the “Confirm Password” prompt, retype the desired password, then press . 4. Select Save to CMOS and EXIT, type , then . To Change Password 1. Choose the Set Password option from the CMOS Setup Utility main menu and press . 2.
4.2.12 Save & Exit Setup If you select this option and press then , the values entered in the setup utilities will be recorded in the chipset’s CMOS memory. The microprocessor will check this every time you turn your system on and use the settings to configure the system. This record is required for the system to operate. 4.2.13 Exit Without Saving Selecting this option and pressing lets you exit the Setup program without recording any new values or changing old ones.
PCM-9584 User Manual 38
CHAPTER 5 PCI Graphic Introduction Installation of PCI Graphic drivers -for Windows 98/2000/XP Further information 39 Chapter 5
Chapter 5 PCI Graphic Setup 5.1 Introduction The PCM-9584 has an onboard PCI/AGP flat panel/VGA interface. The specifications and features are described as follows: 5.1.1 Chipset The PCM-9584 uses a Intel Montara-GM/GM+ GMCH chipset for its graphic controller. It supports LVDS LCD displays, conventional analog CRT monitors, DVI function. 5.1.
1 41 Chapter 5
PCM-9584 User Manual 42
5.2 Installation of the PCI Graphic driver Complete the following steps to install the PCI graphic driver. Follow the procedures in the flow chart that apply to the operating system that you are using within your PCM-9584. Notes: 1. The windows illustrations in this chapter are intended as examples only. Please follow the listed steps, and pay attention to the instructions which appear on your screen. 2. For convenience, the CD-ROM drive is designated as "D" throughout this chapter. 5.2.
PCM-9584 User Manual 44
45 Chapter 5
5.3 Further Information For further information about the AGP/VGA installation in your PCM9584, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Advantech websites: www.advantech.com www.advantech.com.
CHAPTER 6 Audio Setup The PCM-9584 is equipped with an audio interface that records and plays back CD-quality audio. This chapter provides instructions for installing the software drivers included on the audio driver diskettes.
Chapter 6 Audio Setup 6.1 Introduction The PCM-9584's on-board audio interface provides high-quality stereo sound and FM music synthesis (ESFM) by using the Intel ICH4 audio controller. The audio interface can record, compress, and play back voice, sound, and music with built-in mixer control. 6.2 Driver installation 6.2.1 Before you begin Please read the instructions in this chapter carefully before you attempt installation. The audio drivers for the PCM-9584 board are located on the audio driver CD.
6.2.2 Windows 9x/2000/Me/XP drivers Step 1. To install Audio driver for Windows 98/2000/XP, please run the set up wizard "Install Shield Wizard for Realtek AC'97 Audio" in CD-ROM. Example installation steps are shown below.
PCM-9584 User Manual 50
Step 2. In the Hardware Update Wizard window, click "Continue anyway".
Step 3. In the following Hardware Update Wizard window, click "Finish" for Windows to complete audio driver installation.
CHAPTER 7 LAN Configuration • Introduction • Features • Installation of Ethernet Driver for - Windows 2000 Drivers Setup Steps - Windows NT Drivers Setup Steps -Windows Wake-on-LAN Setup 53 Chapter 7
Chapter 7 LAN Configuration 7.1 Introduction The PCM-9584 is equipped with a high-performance 32-bit Ethernet chipset which is fully compliant with IEEE 802.3 100 Mbps CSMA/CD standards. It is supported by major network operating systems. It is also both 100Base-T and 10Base-T compatible. 7.2 Features • Intel 82551 10/100Base-T Ethernet LAN controller • Optional Intel 82541 10/100/1000 Base-T Ethernet LAN controller • Supports Wake-on-LAN remote control function. • PCI Bus Master complies with PCI Rev. 2.
7.3.1 Installation for Windows 98, 2000 & XP To install LAN driver for Windows 98/2000/XP, please run "NetXtreme" in CD-ROM. Example installation steps are shown below.
1.
2.
3.
4.
7.4 Further information Intel website: www.intel.com Advantech websites: www.advantech.com www.advantech.com.
Appendix A Programming the GPIO and Watchdog Timer The PCM-9584 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.
Appendix A Prog. GPIO & W’dog Timer A.1 Supported GPIO Register Below are detailed descriptions of the GPIO addresses and programming sample. A.1.1 GPIO Registers CRF0 (GP10-GP17 I/O selection register. Default 0xFF) When set to a '1', respective GPIO port is programmed as an input port. When set to a '0', respective GPIO port is programmed as an output port. CRF1 (GP10-GP17 data register. Default 0x00) If a port is programmed to be an output port, then its respective bit can be read/written.
A.1.2 GPIO Example program-1 -----------------------------------------------Enter the extended function mode, interruptible double-write -----------------------------------------------MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL --------------------------------------------------------------Configured logical device 7(GP10~GP17), configuration register CRF0,CRF1,CRF2 --------------------------------------------------------------MOV DX,2EH MOV AL,07H; point to Logical Device Number Reg.
OUT DX,AL MOV DX,2FH MOV AL,??H; Put the output value into AL ??H OUT DX,AL -----------------------------------------Exit extended function mode | -----------------------------------------MOV DX,2EH MOV AL,AAH OUT DX,AL PCM-9584 User Manual 64
A.2 Watchdog programming Bellow is a sample of programming code for controlling the Watchdog Timer function.
MOV DX,2EH MOV AL,F6H OUT DX,AL MOV DX,2FH MOV AL,05H; Set 5 seconds OUT DX,AL ;-----------------------------------------; Exit extended function mode | ;-----------------------------------------MOV DX,2EH MOV AL,AAH OUT DX,AL PCM-9584 User Manual 66
Appendix B Pin Assignments This appendix provides specialized information regarding: 67 Chapter B
Table B.1: CN1 Power Connector Part Number 1655412090 Footprint atxcon-2X6-42 Description Power CONN. 6*2 180D W/Fixed Lock 4200-WS-A1 1 3 2 5 7 9 11 6 8 10 4 12 Pin Pin Name Signal Type Signal Level 1 GND GND 2 GND GND 3 +5V PWR 4 GND GND 5 +5V PWR +5V 6 5VSB PWR +5V 7 GND GND 8 PWR_PSON# IN +5V 9 +5V PWR +5V 10 GND GND 11 +5V PWR +5V 12 +12V PWR +12V +5V Table B.
Pin Pin Name Signal Type Signal Level 1 V2.5_LAN1 PWR +2.5V 2 GND GND 3 LAN1_LINKLED OUT 4 LAN2_LINKLED OUT Analog 5 LAN1_ACTLED OUT Analog 6 LAN2_ACTLED OUT Analog 7 LAN1_LINK1000# OUT Analog 8 LAN2_LINK1000# OUT Analog Analog Table B.3: CN4 PCI -5V & -12V Input Part Number 1655303020 Footprint WHL3V-2M Description WAFER BOX 2.
Table B.4: CN5 SYSTEM PANEL Part Number 1653007260 Footprint BH22X2SV Description PIN HEADER SMD 7*2P 180DMALE P=2.
Table B.5: CN6 LAN1 CONNECTOR Part Number 1653205201 Footprint BH5X2DV-2M Description BOX HEADER 5*2P (M) 180D2.
Table B.6: CN7 SATA2 connector Part Number 1654907000 Footprint SATA Description CONN Serial ATA DIP 7P 180D(M) 1.
Table B.7: CN9 SATA1 connector Part Number 1654907000 Footprint SATA Description CONN Serial ATA DIP 7P 180D(M) 1.
Table B.8: CN10 LAN2 CONNECTOR Part Number 1653205201 Footprint BH5X2DV-2M Description BOX HEADER 5*2P (M) 180D2.
Table B.9: CN11 CPU FAN connector Part Number 1655003010 Footprint JH5X2S-2M Description Wafer 2.54mm 3P 180D(M) DIP W/LOCK22272031 Molex 1 2 3 Pin Pin Name Signal Type 1 GND GND 2 +12V PWR 3 FANIO2 OUT Signal Level +12V Table B.10: CN12 USB5/6 connector Part Number 1653005260 Footprint JH5X2S-2M Description PIN HEADER 5*2P 180D(M) 2.
9 GND 10 NC GND Table B.11: CN13 USB3/4 connector Part Number 1653005260 Footprint JH5X2S-2M Description PIN HEADER 5*2P 180D(M) 2.
Table B.12: CN14 USB1/2 connector Part Number 1653005260 Footprint JH5X2S-2M Description PIN HEADER 5*2P 180D(M) 2.0mm SMD Pin Pin Name Signal Type Signal Level 1 USBV1 PWR +5V 2 USBV1 PWR +5V 3 USBD1- I/O USB 4 USBD2- I/O USB 5 USBD1+ I/O USB 6 USBD2+ I/O USB 7 GND GND 8 GND GND 9 GND GND 10 NC Table B.13: CN15 KB/MS Part Number 1653205260 Footprint BH5X2SV Description BOX HEADER DIP 6*1 180D (M) 2.
2 KB-DATA IN +5V 3 MS-CLK IN +5V 4 GND PWR 5 +5V PWR +5V 6 MS-DATA IN +5V Table B.14: CN16 GPIO Part Number 1653005261 Footprint JH5X2S-2M Description PIN HEADER SMD 5*1P 1 2 3 4 5 6 7 8 9 10 180D(M) 2.
Table B.15: CN17 Print Port connector Part Number 1653213260 Footprint BH13X2SV Description BOX HEADER 13*2P 180D(M) 2.
17 PIO_PD7 I/O 18 GND GND 19 LPT_ACK# In 20 GND GND 21 LPT_BUSY In 22 GND GND 23 LPT_PE In 24 GND GND 25 LPT_SLCT In 26 NC +5V +5V +5V +5V +5V Table B.16: CN18 IDE connector Part Number 1653220205 Footprint BH20X2DV-1 Description BOX HEADER 20*2P 180D(M) 2.54mm DIP NO.
2 GND GND 3 DD7 I/O +5V 4 DD8 I/O +3.
36 DA2 In +5V 37 CS#1 Out +5V 38 CS#3 Out +5V 39 DASP# Out +5V 40 GND GND Table B.17: CN19 COM1/2/3/4 connector Part Number 1653220260 Footprint BH20X2SV Description BOX HEADER SMD 20*2P 180D(M) 2.
7 DTRA# I/O +5V 8 RIA# IN +5V 9 GND GND 10 GND GND 11 CM2_1 In +5V 12 DSRB# In +5V 13 CM2_2 In +5V 14 RTSB# I/O +5V 15 CM2_3 Out +5V 16 CTSB# In +5V 17 CM2_4 I/O +5V 18 RIB# In +5V 19 GND GND 20 GND GND 21 DCDC# In +5V 22 DSRC# In +5V 23 SINC In +5V 24 RTSC# I/O +5V 25 SOUTC Out +5V 26 CTSC# In +5V 27 DTRC# I/O +5V 28 RIC# In +5V 29 GND GND 30 GND GND 31 DCDD# In +5V 32 DSRD# In +5V 33 SIND In +5V 34 RTSD#
40 GND GND Table B.18: CN20 PC104+ Connector Part Number 165313222A,165312022A,1653130428 Footprint PC104-PLUS Description Pin Pin Name Signal Type Signal Level Table B.19: CN21 AUDIO connector Part Number 1653208260 Footprint BH8X2SV Description BOX HEADER 8*2P 180D(M) 2.
13 NC 14 MIC_L IN Analog 15 MIC_R IN Analog 16 AGND GND Table B.20: CN22 LVDS Connector Part Number 1653920200 Footprint SPH20X2 Description *CONN. DF13-40DP-1.25V Pin Pin Name Signal Type Signal Level 1 VDD_FP PWR +5V/+3.3V 2 VDD_FP PWR +5V/+3.3V 3 GND 4 GND 5 VDD_FP PWR +5V/+3.3V 6 VDD_FP PWR +5V/+3.
8 LVDS_B_D0N OUT LVDS 9 LVDS_A_D0P OUT LVDS 10 LVDS_B_D0P OUT LVDS 11 GND 12 GND 13 LVDS_A_D1N OUT LVDS 14 LVDS_B_D1N OUT LVDS 15 LVDS_A_D1P OUT LVDS 16 LVDS_B_D1P OUT LVDS 17 GND 18 GND 19 LVDS_A_D2N OUT LVDS 20 LVDS_B_D2P OUT LVDS 21 LVDS_A_D2N OUT LVDS 22 LVDS_B_D2P OUT LVDS 23 GND 24 GND 25 LVDS_A_CLKN OUT LVDS 26 LVDS_B_CLKN OUT LVDS 27 LVDS_A_CLKP OUT LVDS 28 LVDS_B_CLKP OUT LVDS 29 GND 30 GND 31 LVDS_DCLK I/O +3V~+5V 32
Table B.21: CN23 LCD Backlight Part Number 1655305020 Footprint WHL5V-2M Description WAFER BOX 2.0mm 5P 180D MALE W/LOCK 1 2 3 4 5 Pin Pin Name Signal Type Signal Level 1 +12V PWR +12V 2 GND GND 3 LVDS_BKLTEN OUT +3.3V 4 VBR OD +3.3V 5 +5V PWR +5V Table B.22: CN24 CD_IN connector Part Number 1655304020 Footprint WHL4V-2M Description WAFER BOX 2.
Table B.23: CN25 48bit LVDS Connector Part Number 1653920200 Footprint SPH20X2 Description *CONN. DF13-40DP-1.25V Pin Pin Name Signal Type Signal Level 1 VDD_LVDS_PANEL PWR +5V/+3.3V 2 VDD_LVDS_PANEL PWR +5V/+3.3V 3 GND 4 GND 5 VDD_LVDS_PANEL PWR +5V/+3.3V 6 VDD_LVDS_PANEL PWR +5V/+3.
12 GND 13 L1-LVDS0_N1 OUT LVDS 14 L1-LVDS1_N1 OUT LVDS 15 L1-LVDS0_P1 OUT LVDS 16 L1-LVDS1_P1 OUT LVDS 17 GND 18 GND 19 L1-LVDS0_N2 OUT LVDS 20 L1-LVDS1_N2 OUT LVDS 21 L1-LVDS0_P2 OUT LVDS 22 L1-LVDS1_P2 OUT LVDS 23 GND 24 GND 25 L1-LVDS0_CON OUT LVDS 26 L1-LVDS1_CON OUT LVDS 27 L1-LVDS0_COP OUT LVDS 28 L1-LVDS1_COP OUT LVDS 29 GND 30 GND 31 L1-LVDS_CLK I/O +3V~+5V 32 L1-LVDS_DATA I/O +3V~+5V 33 GND 34 GND 35 L1-LVDS0_N3 I/O +3V~+5
Table B.24: CN26 CRT connector Part Number 1653208260 Footprint BH8X2SV Description BOX HEADER 8*2P 180D(M) 2.00mm 1 2 3 4 13 15 14 16 Pin Pin Name Signal Type Signal Level 1 VGA_R OUT Analog 2 VGA VCC5 PWR +5V 3 VGA_G OUT Analog 4 GND GND 5 VGA_B OUT Analog 6 NC 7 NC Analog 8 VGA_DDAT OUT 9 GND GND 10 VGA_HS OUT 11 GND GND 12 VGA_VS OUT 13 GND GND 14 VGA_DCLK OUT 15 GND GND 16 NC PCM-9584 User Manual 90 +2.5V +2.5V +2.
Table B.25: CN27 SYS FAN connector Part Number 1655003010 Footprint JH5X2S-2M Description Wafer 2.54mm 3P 180D(M) DIP W/LOCK22272031 Molex 1 2 3 Pin Pin Name Signal Type 1 GND GND 2 +12V PWR 3 FANIO2 OUT Signal Level +12V Table B.26: CN28 Inverter connector Part Number 1655305020 Footprint WHL5V-2M Description WAFER BOX 2.0mm 5P 180D MALE W/LOCK 1 2 3 4 5 Pin Pin Name Signal Type Signal Level 1 +12V PWR +12V 2 GND GND 3 LVDS1_BKLTEN OUT +3.3V 4 LVDS1_VBR OD +3.
Table B.27: CN29 SPK-OUT connector Part Number 1655304020 Footprint WHL4V-2M Description WAFER BOX 2.0mm 4P 180D MALE W/LOCK 2001-WS-4 Pin Pin Name Signal Type Signal Level 1 SPK_R- OUT Analog 2 SPK_R+ OUT Analog 3 SPK_L+ OUT Analog 4 SPK_L- OUT Analog Table B.28: CN30 Compack II W/Ejector Part Number 1653025215 Footprint COMPACK-T12 Description HEADER for CF Type II 50P 90D(M)Standoff 2.
17 GND GND 18 IDE_PDA2 IN +5V 19 IDE_PDA1 IN +5V 20 IDE_PDA0 IN +5V 21 IDE_PDD0 I/O +5V 22 IDE_PDD1 I/O +5V 23 IDE_PDD2 I/O +5V 24 NC 25 GND 26 NC 27 IDE_PDD11 I/O +5V 28 IDE_PDD12 I/O +5V 29 IDE_PDD13 I/O +5V 30 IDE_PDD14 I/O +5V 31 IDE_PDD15 I/O +5V 32 IDE_PDCS#3 OUT +5V 33 NC 34 IDE_PDIOR# OUT +5V 35 IDE_PDIOW# OUT +5V 36 IDE_WE# OUT +5V 37 IDE_IRQ IN +5V 38 +5V PWR +5V 39 CF_CSEL# OUT +5V 40 NC 41 RESET# OUT +5V 42
50 GND Table B.29: CN31 MINI PCI connector Part Number 16542C4701 Footprint MINIPCI-C Description MINI PCI 124PIN SMD FOR TYPE 3 180D(F) H=5.6 Pin Pin Name Signal Type Signal Level Table B.30: CN32 MIO USB connector Part Number 1653005260 Footprint JH5X2S-2M Description PIN HEADER 5*2P 180D(M) 2.
Appendix C System Assignments This Appendix contains information of a detailed nature: It includes: • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments 95 Appendix C
Appendix C System Assignments C.1 System I/O Ports Table C.1: System I/O Ports Addr.
Table C.1: System I/O Ports Addr. range (Hex) Device MPU-401 select from 300 ~ 330H (2 bytes) C.2 1st MB memory map Table C.2: 1st MB memory map Addr.
C.4 Interrupt assignments Table C.
Appendix D Optional Extras for the PCM-9584 99 Appendix D
Appendix D Optional Extras The PCM-9584 requires several cables for normal operation. You can make them yourself or purchase an optional cable kit assembly, which includes the following D.1 PCM-10586-9584E Cable kit for PCM-9584 Table D.1: PCM-10586-9584E Cable kit for PCM-9584 Part No. Cable Description PCM-9584 connector Terminal Connector 1703060191 KB/Mouse CABLE CN15 Cable 6P-2.
Appendix E Mechanical Drawings 101 Appendix E
Appendix E Mechanical Drawings E.1 Mechanical Drawings 146.05 142.62 140.97 116.84 113.28 99.95 93.35 87.33 24.89 16.76 16.1 14.02 12.95 5.08 4.06 2.84 2.03 105.66 0.00 0.00 H1 H3 5.13 4.62 5.13 15.33 17.83 41.33 49.52 56.44 61.52 65.07 71.81 72.95 73.96 72.44 73.71 76.25 83.87 90.98 94.54 117.08 118.16 129.27 132.89 138.26 141.46 141.61 139.24 149.91 152.45 174.08 177.23 179.58 184.24 188.73 H2 H4 190.8 198.17 199.4 200.33 203.20 143.08 140.97 131.79 127.51 123.83 120.14 113.03 108.
.98 79.82 20.28 203.20 150.67 141.92 114.82 84.92 0.00 114.52 146.05 0.00 Figure E.
PCM-9584 User Manual 104
Appendix F AT/ATX Power setting 105 Appendix F
Appendix F AT/ATX Power setting F.1 Introduction PCM-9584 supports 2 kinds of power mode to boot up system. One is ATX mode, the other is AT mode. ATX should connect standby power and power supply on# signal to turn on main power supply. AT power doesn’t need to connect those two pins: pin 6, pin 8 of PCM-9584. The power connector table & Power supply diagram tables are as bellow: Table F.
ATX power supply diagram ATX Power Supply +5V Pin3 Pin5 Pin9 Pin11 Standby +5V Pin6 PSON# Pin8 +12V Pin12 PCM-9584 Power Connector Pin1 Pin2 Pin4 Pin7 Pin10 GND 107 Appendix F
AT power supply diagram Pin3 Pin5 Pin9 Pin11 Pin6 +5V Pin8 AT Power Supply +12V Pin12 Pin1 Pin2 Pin4 Pin7 Pin10 GND PCM-9584 User Manual 108 PCM-9584 Power Connector
