Gigabit PCI Adapter User’s Manual Model # ALN-318C
Copyright Copyright 2002 by this company. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company.
Contents 1 Introduction ........ 3 1.1 System Requirements ............ 3 1.2 Package Contents ............... 3 2 Hardware Installation Instructions 3 Software Driver Installation ........ 4 ............. 5 3.1 Gigabit PCI Adapter Software Driver Installation Procedures……… ……..5 3.1.1 For Windows ME, 2000 and XP............................................................................. 6 3.1.2 For Windows 98SE ....................................................................................
1. Introduction Gigabit PCI Adapter Installation CD is an All-In-One installation utility for Gigabit PCI Adapter. It automatically detects and installs recently installed Gigabit PCI Adapter hardware under Windows 98SE, ME, 2000, and XP. This utility includes Install Driver and User Manual two sections. Click Install Driver to start Gigabit PCI Adapter driver installation process. User Manual includes specification and hardware/software driver installation instructions for Gigabit PCI adapter. 1.
2. Hardware Installation Instructions 1) Turn off computer and remove its cover. 2) Insert the contact edge of the adapter card into the connector of any available PCI Bus master expansion slot. Press the card firmly into the connector to PCI slot. Please make sure the card’s contacts are fully seated in the PCI slot. 3) Install the bracket screw that secures the card to the Computer chassis. 4) Replace the computer’s cover. 5) Connect the Gigabit NIC card to the network with Ethernet Cable.
3. Software Driver Installation 3.1 Gigabit PCI Adapter Software Driver Installation Procedures Insert Gigabit PCI Adapter Installation CD into CD-ROM drive then window below will appear. Install Driver: Click Install Driver to start Gigabit PCI Adapter installation process. User Manual: Click User Manual to open Gigabit PCI Adapter User Manual Acrobat® Reader 6.0: Adobe Reader 6.0 software to support PDF format file.
3.1.1 For Windows ME, 2000 and XP 1) Once click Install Driver to start the Gigabit PCI Adapter installation, window below will appear 2) After Gigabit PCI Adapter Installation Utility finishes installing corresponding Gigabit PCI Adapter device driver, window below will appear. Click OK to complete the installation process.
3) Click Exit to close Gigabit PCI Adapter Installation Utility.
Figure 2 - Realtek Gigabit PCI Adapter Figure 3 – IC Plus Gigabit PCI Adapter 8
3.1.2 For Windows 98SE 1) Once click Install Driver to start the Gigabit PCI Adapter installation, window below will appear: 2) After Gigabit PCI Adapter Installation Utility finishes copying Gigabit PCI Adapter device driver, window below will appear then click OK to reboot your system.
3) For & Gigabit PCI Adapters: Æ After system boots up, the device driver will be installed completely. For Gigabit PCI Adapters: (a) After system boots up, operating system will detect the recently installed Gigabit PCI adapter, window below will appear then click Next to continue.
(c) Select Specify a location (utility automatically gives driver location, so you don’t have to enter the driver location path) then click Next to continue, (d) Click Next to continue, 11
(e) For Windows 98SE, system will ask you to insert Windows 98SE installation CD, Please insert the CD and click “OK”, (f) Enter correct file path and click “OK”, (g) After operating system finishes installing the Gigabit PCI Adapter driver, click Finish to complete the device driver installation, 12
(h) To finish setting up your new device driver installation, operating system will show message and ask to restart your computer. Click “Yes” to complete the System Settings Change. (i) To check if Gigabit PCI Adapter is properly installed: i. Right-click “My Computer” on the Desktop ii. Choose “Properties” iii.
3.1.3 For Windows 98 First Edition < For IC PLUS/Realtek> When system boots up first time with new Gigabit PCI adapter presents, Windows operation system will detect new hardware and ask for hardware driver. Put Gigabit PCI Adapter driver install CD from product package into CD-ROM drive and go to device driver CD Location, and then find your new Gigabit PCI Adapter device driver.
3.1.7 For Netware x 1) Login to Netware x after install Marvell Gigabit PCI Adapter. 2) Put Gigabit PCI Adapter installation CD from product package into CD-ROM drive and go to device driver CD location, and then find Marvell Gigabit PCI Adapter device driver. Example: E:\DRIVER\MARVELL\MARVELL SERVER\yukonnw_x_vxxxx 3) Follow the installation instruction in “yukonnw.txt” to complete the installation. 3.
