UNO-3072LA User Manual 38
Table A.4: Connector and Jumper Descriptions
Location Label Function
Main-
board
CN7 Internal USB
CN9/CN12 Gigabit LAN/USB Connector
CN14 SATA Connector
CN17, CN18 Optional Cable Wired COM3/COM4 pin header
CN19 Optional Cable Wired PS/2 pin header
CN20 Clear CMOS
CN21 Print Port Pin header
CN22, CN23 LVDS /LVDS power (Reserved)
CN24, CN25 CF1/ CF2
CN27 DO status after reset Jumper
CN28, CN29 COM port RS-232/RS-422&485 selection
CN30 COM1/COM2 DB-9 connector
CN33 3P Fan power connector
CN39 Video detect Jumper for Dual DVI-D selection
(Close:Disable VGA)
CN41 Optional Cable Wired USB pin header
SW3 CF1/CF2 Master selection
SW6 (Reserved)
