44 PCM-9550F/FM/L User's Manual
3.2.5 Connections to Toshiba LTM12C275A
(800 x 600 TFT color LCD)
Table 3-5: Connections to Toshiba LTM12C2775A
LTM12C275A PCM-9550F/FM CN14
Pin Name Pin Name
1 GND 3 GND
2 NCLK 35 SHFCLK
3NC -NC
4NC -NC
5 GND 4 GND
6 R0 27 P18
7 R1 28 P19
8 R2 29 P20
9 R3 30 P21
10 R4 31 P22
11 R5 32 P23
12 GND 8 GND
13 G0 19 P10
14 G1 20 P11
15 G2 21 P12
16 G3 22 P13
17 G4 23 P14
18 G5 24 P15
19 GND 33 GND
20 B0 11 P2
21 B1 12 P3
22 B2 13 P4
23 B3 14 P5
24 B4 15 P6
25 B5 16 P7
26 ENAB 37 M/DE
27 GND 34 GND
28 VCC 5 +5 V
29 VCC 6 +5 V
30 GND 39 GND
