B.14 External Speaker (CN17)

The CPU card has its own buzzer. You can also connect it to the

external speaker on your computer chassis.

External speaker (CN17)

Pin Function

1 +5 V

2 GND

3 Internal buzzer

4 Speaker out

B.15 Reset Connector (CN18)

Reset connector (CN18)

Pin Signal

1 GND

2 Reset

B.16 HDD LED Connector (CN19)

HDD LED connector (CN19)

Pin Signal

2 LED
