Appendix B Pin Assignments 111
B.12 CPU Fan Power Connector (CN14)
CPU fan power connector (CN14)
Pin Signal
1 GND
2 +12 V
3 Detect
B.13 Power LED and Keylock Connector
(CN16)
You can use an LED to indicate when the CPU card is on. Pin 1 of
CN16 supplies the LED's power, and Pin 3 is the ground.
You can use a switch (or a lock) to disable the keyboard so that the
PC will not respond to any input. This is useful if you do not want
anyone to change or stop a program which is running. Simply
connect the switch from Pin 4 to Pin 5 of CN16.
Power LED and keylock connector (CN16)
Pin Function
1 LED power (+5 V)
2NC
3 GND
4 Keyboard lock
5 GND
123
