110 PCA-6176 User's Manual
B.9 Keyboard and Mouse Connnector
(CN11)
Keyboard and mouse connector (CN11)
Pin Signal
1 KB DATA
2 MS DATA
3 GND
4V
CC
5 KB CLOCK
6 MS CLOCK
B.10 External Keyboard Connector (CN12)
External keyboard connector (CN12)
Pin Signal
1 CLK
2 DATA
3NC
4 GND
5V
CC
B.11 IR Connector (CN13)
IR connector (CN13)
Pin Signal Pin Signal
1 +5 V 2 N/C
3 FIRRX 4 CIRRX
5 IR_RX 6 +5VSB
7 GND 8 N/C
9 IR_TX 10 N/C
