Appendix B Pin Assignments
109
B.7 Ethernet 10Base-T RJ-45 Connector
(CN8)
Ethernet 10Base-T RJ-45 connector (CN8)
Pin Signal
1 XMT+
2 XMT-
3 RCV+
4 N/C
5 N/C
6 RCV-
7 N/C
8 N/C
B.8 COM1/COM2 RS-232 Serial Port
(CN9, CN10)
COM1/COM2 RS-232 serial port (CN9/CN10)
Pin Signal
1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9RI
