User manual

UTCA-5503 User Manual 52
D.1 IPMI/PICMG Command Subset Supported by the
uShM
Table D.1: IPMI/PICMG Command Subset Supported by the uShM
Command IPMI Spec NetFn CMD MTCA.0 Req
IPM Device “Global” Commands
Get Device ID 17.1 App 01h Mandatory
Cold Reset 17.2 App 02h Optional
Warm Reset 17.3 App 03h Optional
Get Self Test Results 17.4 App 04h Mandatory
Get Device GUID 17.8 App 08h Optional
BMC Device and Messaging Support Commands
Send Message 18.7 App 34h Mandatory
Get System GUID 18.13 App 37h Optional
Get Channel Authentication
Capabilities
18.12 App 38h Mandatory
Get Session Challenge 18.14 App 39h Mandatory
Activate Session 18.15 App 3Ah Mandatory
Set Session Privilege Level 18.16 App 3Bh Mandatory
Close Session 18.17 App 3Ch Mandatory
Get Session Info 18.18 App 3Dh Mandatory
Set Channel Access 18.20 App 40h Mandatory
Get Channel Access 18.21 App 41h Mandatory
Get Channel Info 18.22 App 42h Mandatory
Set User Access 18.23 App 43h Mandatory
Get User Access 18.24 App 44h Mandatory
Set User Name 18.25 App 45h Mandatory
Get User Name 18.26 App 46h Mandatory
Set User Password 18.27 App 47h Mandatory
Event Commands
Platform Event 23.3 S/E 02h Mandatory
PEF and Alerting Commands
Get PEF Capabilities 24.1 S/E 10h Mandatory
Set PEF Configuration Parameters 24.3 S/E 12h Mandatory
Get PEF Configuration Parameters 24.4 S/E 13h Mandatory
Set Last Processed Event ID 24.5 S/E 14h Mandatory
Get Last Processed Event ID 24.6 S/E 15h Mandatory
PET Acknowledge 24.8 S/E 17h Optional
Sensor Device Commands
Get Device SDR Info 29.2 S/E 20h Mandatory
Get Device SDR 29.3 S/E 21h Mandatory
Reserve Device SDR Repository 29.4 S/E 22h Mandatory
Get Sensor Reading Factors 29.5 S/E 23h Optional
Set Sensor Hysteresis 29.6 S/E 24h Optional
Get Sensor Hysteresis 29.7 S/E 25h Optional
Set Sensor Threshold 29.8 S/E 26h Optional
Get Sensor Threshold 29.9 S/E 27h Optional
