UTCA-5503 User Manual 48
C.1 IPMI/PICMG Command Subset Supported by the
Carrier Manager
Table C.1: IPMI/PICMG Command Subset Supported by the Carrier
Manager
Command
IPMI/PICMG/
AMC/MTCA
Spec
NetFn CMD
Carrier
Manager Req
IPM Device “Global” Commands
Get Device ID 17.1 App 01h Mandatory
Broadcast “Get Device ID” 17.9 App 01h Mandatory
Event Commands
Platform Event 23.3 S/E 02h Mandatory
Sensor Device Commands
Get Device SDR Info 29.2 S/E 20h Mandatory
Get Device SDR 29.3 S/E 21h Mandatory
Reserve Device SDR Repository 29.4 S/E 22h Mandatory
Get Sensor Reading Factors 29.5 S/E 23h Optional
Set Sensor Hysteresis 29.6 S/E 24h Optional
Get Sensor Hysteresis 29.7 S/E 25h Optional
Set Sensor Threshold 29.8 S/E 26h Optional
Get Sensor Threshold 29.9 S/E 27h Optional
Set Sensor Event Enable 29.10 S/E 28h Optional
Get Sensor Event Enable 29.11 S/E 29h Optional
Rearm Sensor Events 29.12 S/E 2Ah Optional
Get Sensor Event Status 29.13 S/E 2Bh Optional
Get Sensor Reading 29.14 S/E 2Dh Mandatory
FRU Device Commands
Get FRU Inventory Area Info 28.1 Storage 10h Mandatory
Read FRU Data 28.2 Storage 11h Mandatory
Write FRU Data 28.3 Storage 12h Mandatory
AdvancedTCA Commands
Get PICMG Properties 3-10 PICMG 00h Mandatory
FRU Control 3-25 PICMG 04h Mandatory
Get FRU LED Properties 3-27 PICMG 05h Mandatory
Get LED Color Capabilities 3-28 PICMG 06h Mandatory
Set FRU LED State 3-29 PICMG 07h Mandatory
Get FRU LED State 3-30 PICMG 08h Mandatory
Get Device Locator Record ID 3-35 PICMG 0Dh Mandatory
Get Fan Speed Properties 3-81 PICMG 14h Mandatory
Set Fan Level 3-83 PICMG 15h Mandatory
Get Fan Level 3-82 PICMG 16h Mandatory
FRU Control Capabilities 3-24 PICMG 1Eh Mandatory
AMC Commands
Set AMC Port State 3-26 PICMG 19h Mandatory
Get AMC Port State 3-27 PICMG 1Ah Mandatory
MicroTCA Commands
