41 UTCA-5503 User Manual
Appendix A MCH Pin List, Connector 1
42 PWR 129 I2C_SDA
41 ENABLE# 130 I2C_SCL
40 GND 131 GND
39 RxFA-7- 132 RSVD
38 RxFA-7+ 133 TMREQ#
37 GND 134 GND
36 TxFA-7- 135 RxFA-8-
35 TxFA-7+ 136 RxFA-8+
34 GND 137 GND
33 RxFA-5- 138 TxFA-8-
32 RxFA-5+ 139 TxFA-8+
31 GND 140 GND
30 TxFA-5- 141 RxFA-6-
29 TxFA-5+ 142 RxFA-6+
28 GND 143 GND
27 PWR 144 TxFA-6-
26 GA2 145 TxFA-6+
25 GND 146 GND
24 RxFA-3- 147 RxFA-4-
23 RxFA-3+ 148 RxFA-4+
22 GND 149 GND
21 TxFA-3- 150 TxFA-4-
20 TxFA-3+ 151 TxFA-4+
19 GND 152 GND
18 PWR 153 RxFA-2-
17 GA1 154 RxFA-2+
16 GND 155 GND
15 RxFUA- 156 TxFA-2-
14 RxFUA+ 157 TxFA-2+
13 GND 158 GND
12 TxFUA- 159 RxFA-1-
11 TxFUA+ 160 RxFA-1+
10 GND 161 GND
9 PWR 162 TxFA-1-
8 RSVD 163 TxFA-1+
7 GND 164 GND
6 RSVD 165 TCK
5 GA0 166 TMS
4 MP 167 TRST#
3 PS1# 168 TDO
2 PWR 169 TDI
1 GND 170 PWR_ON
Table A.1: MCH Pin List, Connector 1
