UTCA-5503 User Manual 40
A.1 MCH Pin List, Connector 1
Table A.1: MCH Pin List, Connector 1
Pin No. Signal Pin No. Signal
85 GND 86 GND
84 PWR 87 IPMBL-SDA-12
83 PS0# 88 IPMBL-SCL-12
82 GND 89 GND
81 XOVER2- 90 IPMBL-SDA-11
80 XOVER2+ 91 IPMBL-SCL-11
79 GND 92 GND
78 XOVER1- 93 IPMBL-SDA-10
77 XOVER1+ 94 IPMBL-SCL-10
76 GND 95 GND
75 XOVER0- 96 IPMBL-SDA-9
74 XOVER0+ 97 IPMBL-SCL-9
73 GND 98 GND
72 PWR 99 IPMBL-SDA-8
71 SDL_L 100 IPMBL-SCL-8
70 GND 101 GND
69 RxFA-12- 102 IPMBL-SDA-7
68 RxFA-12+ 103 IPMBL-SCL-7
67 GND 104 GND
66 TxFA-12- 105 IPMBL-SDA-6
65 TxFA-12+ 106 IPMBL-SCL-6
64 GND 107 GND
63 RxFA-12- 108 IPMBL-SDA-5
62 RxFA-12+ 109 IPMBL-SCL-5
61 GND 110 GND
60 TxFA-11- 111 IPMBL-SDA-4
59 TxFA-11+ 112 IPMBL-SCL-4
58 GND 113 GND
57 PWR 114 IPMBL-SDA-3
56 SCL_L 115 IPMBL-SCL-3
55 GND 116 GND
54 RxFA-10- 117 IPMBL-SDA-2
53 RxFA-10+ 118 IPMBL-SCL-2
52 GND 119 GND
51 TxFA-10- 120 IPMBL-SDA-1
50 TxFA-10+ 121 IPMBL-SCL-1
49 GND 122 GND
48 RxFA-9- 123 IPMB0-SDA-B
47 RxFA-9+ 124 IPMB0-SCL-B
46 GND 125 GND
45 TxFA-9- 126 IPMB0-SDA-A
44 TxFA-9+ 127 IPMB0-SCL-A
43 GND 128 GND
