UTCA-5503

UTCA-5503 User Manual 26

<_>: Actual Shelf Manager IP address is 172.21.35.102

<_>: Actual gateway IP address is 172.21.35.102

<_>: Actual subnetwork mask is 255.255.255.0

<_>: Shelf Info record was found

<_>: reading and parsing MCMC FRU Info

<_>: found an AMC Point-to-Point Connectivity record

<_>: found a Module Current Requirements record

<_>: requested payload current = 1.0A

<_>: AMC # 1: FRU state M0->M0, cause = 7

<_>: AMC # 2: FRU state M0->M0, cause = 7

<_>: AMC # 3: FRU state M0->M0, cause = 7

<_>: AMC # 4: FRU state M0->M0, cause = 7

<_>: AMC # 5: FRU state M0->M0, cause = 7

<_>: AMC # 6: FRU state M0->M0, cause = 7

<_>: AMC # 7: FRU state M0->M0, cause = 7

<_>: AMC # 8: FRU state M0->M0, cause = 7

<_>: AMC # 9: FRU state M0->M0, cause = 7

<_>: CU # 1: FRU state M0->M0, cause = 7

<_>: CU # 2: FRU state M0->M0, cause = 7

<_>: PM # 1: FRU state M0->M0, cause = 7

<_>: PM # 2: FRU state M0->M0, cause = 7

<_>: discovering the current power configuration

<_>: PM # 1: trying to discover the module

<_>: PM # 1: returned from autonomous mode

<_>: MCH FRU state: M1->M2, cause = 3

<_>: MCH FRU state: M2->M3, cause = 1

<_>: Event from ShM Sensor #0 "Hot Swap ShMM": raw 04 F0 00 6F A2 31

<_>: Event from ShM Sensor #0 "Hot Swap ShMM": raw 04 F0 00 6F A3 12

<_>: PM # 1: reading and parsing Module FRU info

<_>: PM # 1: Power Module Capability record found

<_>: PM # 1: maximum PM current = 30.0A

<_>: PM # 1: reading, validating and merging Module SDRs

<_>: PM # 1: added 6 SDR(s), 5 sensor(s)

<_>: PM # 1: FRU state M3->M4, cause = 3

<_>: CU # 1: trying to discover the module

<_>: CU # 1: reading and parsing Module FRU info

<_>: CU # 1: found a Module Current Requirements record

<_>: CU # 1: requested payload current = 3.0A

<_>: CU # 1: reading, validating and merging Module SDRs

<_>: CU # 1: added 9 SDR(s), 8 sensor(s)

<_>: CU # 1: hot swap handle is closed

<_>: CU # 1: FRU state M3->M4, cause = 3

<_>: PM # 1: power budget is 27.0A

<_>: CU # 1: assigned to PM # 1

<_>: PM # 1: power budget is 26.0A

<_>: MCH # 1: assigned to PM # 1
