25 UTCA-5503 User Manual
Chapter 4 Operations
<_>: found site: AMC # 6
<_>: found site: AMC # 7
<_>: found site: AMC # 8
<_>: found site: AMC # 9
<_>: found site: MCH # 2
<_>: found site: PM # 2
<_>: found site: CU # 2
<_>: Carrier Power Policy record was found
<_>: found PM #1 (role: primary)
<_>: found PM #2 (role: standby)
<_>: Carrier Activation and Power Management record was found
<_>: allowance for module activation readiness: 5
<_>: PM # 1 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 0.0A
<_>: PM # 2 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 0.0A
<_>: CU # 1 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: CU # 2 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: MCH # 1 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: MCH # 2 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: AMC # 1 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: AMC # 2 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: AMC # 3 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: AMC # 4 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: AMC # 5 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: AMC # 6 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: AMC # 7 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: AMC # 8 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: AMC # 9 auto activation = 01 auto deactivation = 01, power-
on delay = 0.0s, max site current = 7.0A
<_>: Shelf Manager Fan Geography record found
<_>: CU # 1: AMC # 1 AMC # 2 AMC # 3 AMC # 4 AMC # 5 AMC # 6
<_>: CU # 1: AMC # 7 AMC # 8 AMC # 9 CU # 1 CU # 2 PM # 1
<_>: CU # 1: PM # 2 MCH # 1 MCH # 2
<_>: CU # 2: AMC # 1 AMC # 2 AMC # 3 AMC # 4 AMC # 5 AMC # 6
<_>: CU # 2: AMC # 7 AMC # 8 AMC # 9 CU # 1 CU # 2 PM # 1
<_>: CU # 2: PM # 2 MCH # 1 MCH # 2
<_>: found a Carrier Point-to-Point Connectivity record
<_>: found a Carrier Point-to-Point Connectivity record
<_>: found a Carrier Point-to-Point Connectivity record
<_>: found a Carrier Point-to-Point Connectivity record
<_>: Shelf Manager IP address record was found
<_>: Shelf Manager #1 IP address: 172.21.35.102
<_>: Subnet #1 mask: 255.255.255.0
<_>: Gateway #1 IP address: 0.0.0.0
<_>: Shelf Manager #2 IP address: 172.21.35.108
<_>: Subnet #2 mask: 255.255.255.0
<_>: Gateway #2 IP address: 0.0.0.0
