UTCA-5503 User Manual 2
1.1 Technical Data
Table 1.1: Advantech UTCA-5503 MCH Technical Data
MCH module Standard MCH module (PCB Level 1), single width, full size
Application/Security
Processor
Optional on PCB Level 3
Serial Interface
COM1 exposed to front panel as USB Slave interface through
onboard USB/Serial converter, USB1.1 compliant
Ethernet
· 10/100BT Management LAN on Front panel (RJ45, labeled as
LAN1, which may also be 10/100/1000BT Fabric LAN when
MLAN is routed through base fabric switch )
· 10/100/1000BT Fabric LAN on Front panel (RJ45, labeled as
LAN2)
· SFP Socket Fabric LAN on Front panel (alternative option)
· 1000BX GBE base fabric interface to backplane (12x)
· 1000BX GBE update channel to other MCH
· Management LAN may be routed through base fabric switch
(option)
· Front panel ports may be routed over PCB Level 3
· SGMII Interface from PCB Level 3 into base fabric switch
Extension Capabilities Through backplane/PCB Level 2...PCB Level 4
System Management
Controller
· Renesas H8S/2166 based microcontroller as MCMC
· Pigeon Point System based firmware solution
· Carrier manager
· Shelf manager (by default); optional to exclude uShM
Watchdog A programmable watchdog is implemented in MCMC
GbE switch controller Two Marvell 88E6185 gigabit Ethernet switches
GbE PHY Two Marvell 88E1111 single-port gigabit Ethernet transceivers
10/100 Ethernet MAC/
PHY
One SMSC LAN9115 Ethernet controller
FPGA One Lattice LFXP6C programmable device
SRAM One Renesas M5M5V216ATP-55HI 2Mb static RAM
Flash memory One Macronix MX29LV160CBTC-70G 16Mb flash memory
Power consumption
3.3 V 70 mA (max.), 42 mA (60% max.) Mgmt power
12 V 1000 mA (max.), 600 mA (60% max.) Input voltage
Environmental
conditions
Temperature and humidity
(operating)
GR-63-CORE, Issue 3, R4-6
Temperature and humidity
(non-operating)
IEC60068-2-1, IEC 60068-2-3,
IEC 60068-2-2
Altitude
GR-63-CORE, Issue 3, R4-8 4-9,
4-10, O4-11,O4-12
Vibration (operating) IEC 60068-2-64
Vibration (non-operating) IEC 60068-2-6
Shock (operating) IEC 60068-2-27
Shock (non-operating) IEC 60068-2-27
