value for some parameters and non-default values for other parameters. The
default settings for the two new QoS alarm types are:
Note: Only the fault thresholds are configurable; all other parameters must be set to
0. For information about setting the fault thresholds, see Section 1.19.2,
“Setting the Fault Thresholds”, on page 63.
c. Call ipm_SetQoSThreshold( ) to use the QoS parameter values set in step 1b.
2. Enable QoS alarms and start media streaming:
a. Call ipm_EnableEvents( ) to enable QoS monitoring for a list of alarm types.
(QoS monitoring for the new QoS alarms is disabled by default.) The events for
the two new QoS alarm types are:
EVT_RTCPTIMEOUT - timeout event indicating RTCP packets are no longer
being received
EVT_RTPTIMEOUT - timeout event indicating RTP packets are no longer being
received
b. Call ipm_StartMedia( ) to start media streaming and begin QoS monitoring.
3. Monitor QoS alarm notification events:
a. When a QoS alarm has been triggered, an IPMEV_QOS_ALARM event is
generated by the system. Call the Standard Runtime Library function
sr_getevttype( ) to return the event type.
b. Use Standard Runtime Library API functions such as sr_getevtdatap( ) to query
the IPM_QOS_ALARM_DATA structure to learn whether the alarm state is on or
off.
Note: For Dialogic
®
IPT Boards, the system software sends a QoS alarm event
containing ALARM_STATE_ON when a fault threshold is exceeded, but does
not report a QoS event containing ALARM_STATE_OFF when the threshold
returns to the programmed level. An RTCP/RTP timeout alarm is reset either
on resumption of RTCP/RTP packets, end of RTP session, or end of call, but
no notification is sent to the application when the alarm is reset.
4. Perform clean-up activities:
a. Call ipm_Stop( ) to stop media streaming.
b. Call ipm_DisableEvents( ) to stop QoS parameter monitoring.
1.19.2 Setting the Fault Thresholds
The fault thresholds in the IPM_QOS_THRESHOLD_DATA structure for the RTCP and
RTP timeouts can be set as follows:
QoS Type
Time
Interval (ms)
Debounce
On (ms)
Debounce
Off (ms)
Fault
Threshold
%Success
Threshold
%Fail
Threshold
QOSTYPE_
RTCPTIMEOUT
0 0 0 250(x100 msec
= 25 sec)
00
QOSTYPE_
RTPTIMEOUT
0 0 0 1200(x100
msec = 120
sec)
00
