3 FPM-5151G/5171G/5191G Series User Manual
Chapter 1 General Information
1.3 LCD Specification
1.4 Connectors
The following connectors are situated on the left hand side of the FPM-5151G/
5171G/5191G series:
 VGA Port (DB-15)
This DB-15 connector can be connected to the system via the external 15-pin
DB-15 connector located on the left side of the system unit.
 DVI Port (DVI-D)
Connected with a standard DVI connector thru I/O port of this unit. Only sup-
ports digital signals
 Touchscreen Connector (DB-9) (optional)
This connector will be present only if a touchscreen is installed. It must be con-
nected to the RS-232 port of the PC. The touchscreen cable is included with all
orders which include the touchscreen option.
 Touchscreen Connector (USB) (Optional)
This connector will be present only if a touchscreen is installed. It must be con-
nected to the USB port of the PC. The touchscreen cable is included with all
orders which include the USB touchscreen option.
 Plug-In Block 3P Male (ME050-50803) DC12-30V
This block connector can be connected via the external plug-in block 3P with
flanges Female MC211-F103 connector
FPM-5151 FPM-5171 FPM-5191
Display Type XGA TFT (LED) SXGA TFT (LED) SXGA TFT (LED)
Display Size 15” 17” 19”
Max. Colors 16.2M 16.7M 16.7M
Max. Resolution 1024 x 768 1280 x 1024 1280 x 1024
View Angle (H/V°) 160/140 170/160 170/160
Luminance 400 cd/m2 350 cd/m2 350 cd/m2
Storage Temperature -40 ~ 85°C -30 ~ 85°C -20 ~ 60°C
Operating Temperature 0 ~ 50°C 0 ~ 50°C 0 ~ 50°C
Contrast Ratio 700:1 1000:1 1000:1
Lamp Life Time(MTBF) 50,000 hrs. 50,000 hrs. 50,000 hrs.
Note! RS-232 & USB touchscreen interface does not allow connection into the
system at the same time, but it can be changed via switch.
