User manual

FPM-5151G/5171G/5191G Series User Manual 2
1.1 Introduction
Advantech's FPM-5151G/5171G/5191G is a 15"/17”/19” color TFT LCD flat panel
monitor built specifically for industrial applications. With the optional touchscreen,
FPM-5151G/5171G/5191G is an excellent and user-friendly system control interface.
In addition to its usual application as an LED panel monitor,FPM-5151G/5171G/
5191G comes standard with direct VGA and DVI control signal inputs, making it
compatible with Industrial PCs and Workstations. Its OSD (On Screen Display)
function allows you to adjust display factors such as brightness, contrast, colors and
VGA signal information. Functions that are more and more critical as HMI users
become aware of the benefits of flat panel monitors. The whole chassis is of stainless
steel, and the front panel is of aluminum with NEMA4/IP65 compliance.
FPM-5151G/5171G/5191G also comes in a touch screen version (FPM-5151G-R/
FPM-5171G-R/FPM-5191G-R). With an 5-wire resistive type touchscreen, this
monitor can be immediately transformed into a remote control system. The
Advantech FPM-5151G/5171G/5191G is the ultimate HMI solution for your industrial
application.
1.2 Specifications
1.2.1 General
1.2.2 Touchscreen (Optional)
FPM-5151 FPM-5171 FPM-5191
Construc-
tion
Heavy-duty aluminum and steel chassis
Front panel Aluminum, NEMA4 / IP65 Compliant
Control OSD (On Screen Display) control pad on rear
Mounting Panel, wall, desktop, VESA ARM or rack (with rackmount)
Dimensions
(W x H x D)
449.92 x 315.63 x 50.5 mm
(17.71”x 12.43”x 2”)
481.9 x 355.9 x 55 mm
(18.97”x 14.01”x 2.17”)
481.93 x 384.6 x 59 mm
(18.97”x 15.14”x 2.32”)
Weight 6 kg (13.22 lbs) 8 kg (17.63 lbs) 10 kg (22.04 lbs)
FPM-5151 FPM-5171 FPM-5191
Type 5 wire, analog resistive
Resolution 2048*2048
Controller USB & RS-232 interface
Power Consump-
tion
+5 V @ 200 mA
Life Span 100 million activation (typical) at a single point with a 5/8"
diameter silicone finger with a 350 g load at 2 touches per second
