用户手册 FPM-5151G/5171G/ 5191G Series 15" XGA/17" SXGA/19" SXGA Industrial Monitor with Resistive Touchscreen, Direct-VGA, DVI Ports and DC12-30V Inputs
Copyright The documentation and the software included with this product are copyrighted 2012 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable.
Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.
Declaration of Conformity This device complies with part 15 of the FCC rules: Operation is subject to the following two condition: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. FCC Class A Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
Safety Instructions 1. 2. 3. Read these safety instructions carefully. Keep this User Manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible. 5. Keep this equipment away from humidity. 6. Put this equipment on a reliable surface during installation.
FPM-5151G/5171G/5191G Series User Manual vi
Contents Chapter 1 General Information ............................1 1.1 1.2 Introduction ............................................................................................... 2 Specifications ............................................................................................ 2 1.2.1 General ......................................................................................... 2 1.2.2 Touchscreen (Optional) ................................................................
B.2.8 B.2.9 B.2.10 B.2.11 B.2.12 Auto Configuration Menu ............................................................ 26 Mode Information Menu.............................................................. 27 Memory Recall Menu.................................................................. 28 Exit Menu.................................................................................... 29 Hot Keys .....................................................................................
Chapter 1 1 General Information Sections include: Introduction Specifications LCD Specification Power Consumption Connectors Dimensions
1.1 Introduction Advantech's FPM-5151G/5171G/5191G is a 15"/17”/19” color TFT LCD flat panel monitor built specifically for industrial applications. With the optional touchscreen, FPM-5151G/5171G/5191G is an excellent and user-friendly system control interface. In addition to its usual application as an LED panel monitor,FPM-5151G/5171G/ 5191G comes standard with direct VGA and DVI control signal inputs, making it compatible with Industrial PCs and Workstations.
FPM-5171 FPM-5191 Display Type XGA TFT (LED) SXGA TFT (LED) SXGA TFT (LED) Display Size 15” 17” 19” Max. Colors 16.2M 16.7M 16.7M Max. Resolution 1024 x 768 1280 x 1024 1280 x 1024 View Angle (H/V°) 160/140 170/160 170/160 Luminance 400 cd/m2 350 cd/m2 350 cd/m2 Storage Temperature -40 ~ 85°C -30 ~ 85°C -20 ~ 60°C Operating Temperature 0 ~ 50°C 0 ~ 50°C 0 ~ 50°C Contrast Ratio 700:1 1000:1 1000:1 Lamp Life Time(MTBF) 50,000 hrs. 50,000 hrs. 50,000 hrs. 1.
1.5 Dimensions 3DQHO &XW RXW 'LPHQVLRQ [ PP [ Figure 1.
Chapter 1 3DQHO &XW RXW 'LPHQVLRQ [ PP [ FPM-5151G/5171G/5191G Series User Manual 5 General Information Figure 1.
3DQHO &XW RXW 'LPHQVLRQ [ PP [ Figure 1.
Chapter 2 Mounting Wall Mounting Panel Mounting Rack Mounting Desktop Mounting Swing Arm Mounting 2
2.1 Mounting the Monitor The FPM-5151G/5171G/5191G Series can be mounted in many different ways. The versatility of the FPM-5151G/5171G/5191G mounts enable it to be mounted on your desk or anywhere else. 2.1.1 Wall Mounting (Optional) FPM-5151G/5171G/5191G can be mounted directly on a wall with panel mounting brackets. Customers must order the stand kit for FPM-5151G/5171G/5191G. Please refer to Figure 2.
FPM-5151G/5171G/5191G can be mounted directly on a panel with additional mounting brackets. Please refer to Figure 2.2 and follow the following steps: Note! Fix 10pcs panel bracket around the industrial monitor, refer to the below figure. Fix into the panel by screwing the bracket. Figure 2.2 Panel Mounting Figure 2.3 Panel Mounting 9 FPM-5151G/5171G/5191G Series User Manual Mounting 1. 2. You can use the materials provided in the accessory box for panel mounting! Chapter 2 2.1.
2.1.3 Rack Mounting (Optional) If you need to install the FPM-5151G/5171G/5191G on a rack, you must order the rack mounting kit for FPM-5151G/5171G/5191G. Attach the rack mounting brackets on FPM-5151G/5171G/5191G with the screws, then affix the monitor in the rack. Refer to Figure 2.3 for FPM-5151G’s rack mounting. Refer to Figure 2.4 for FPM-5171G’s rack mounting. Refer to Figure 2.5 for FPM-5191G’s rack mounting. Note: Part No. of FPM-5151G’s optional rack mounting kit: Part No.
Chapter 2 Mounting Figure 2.5 FPM-5171 Rack Mounting Figure 2.
2.1.4 Desktop, Swing-ARM Mounting The FPM-5151G/5171G/5191G Series can be mounted in other ways, such as desktop and swing-arm. 2.1.4.1 Desktop Stand FPM-5151G/5171G/5191G can be mounted as stand in the desk directly by a additional mounting brackets. Customers must order the stand kit for FPM-5151G/ 5171G/5191G. Please refer to figure 2.6 and follow these steps: Note (The below optional mounting kit can also be used for wall mounting, refer to section 2.1.4.1 for detail information.) Part No.
Chapter 2 2.1.4.2 Swing Arm (VESA Compliant) FPM-5151G/5171G/5191G has been designed with support for the VESA Arm standard. Refer to figure 2.7. Supports both 75mm and 100mm VESA dimension. Mounting Figure 2.
FPM-5151G/5171G/5191G Series User Manual 14
Appendix A Touchscreen A
A.1 Introduction The FPM-5151G/5171G/5191G Series optional touchscreen uses advanced 5-wire resistive technology. It provides more accurate sensing capacity than other technologies. The touchscreen is specially designed for tough industrial environments, and has been approved to FCC Class A standards. Note! RS-232 & USB touchscreen interface does not allow connection to the system at the same time. It can be changed by switch. A.2 Touchscreen Specifications A.2.
Appendix B OSD Operation Keypad B
B.1 OSD Board Overview The OSD keypad, including six keys and a two color indicator, is designed as the OSD operation interface. B.1.1 OSD Button Description Table B.1: OSD Button Description Power Turn the monitor power ON or OFF. Auto/Exit Automatically adjust the clock, phase, H-position and V-position. Exit menu. Down/Right/Increase Increase the brightness. Move the selector to the next option. Increase the gauge value of the selected option. Up/Left/Decrease Decrease the brightness.
Table B.2: LED Function ON Green StandBy/OFF Green Blinking No Signals Orange B.2 OSD Key Functions Each selected value is stored into LCD memory after SEL signal input or time out. The stored values are not affected if the power is turned off. But the selected value is not available in case a selected mode is changed before time out or power is turned off before time out. TIME OUT -> 5-6 seconds ( Can be set in OSD Manager) The default definition of input keys is shown as following: B.2.
B.2.2 Input Source Select Generate Main Menu Select by Left and Right Button, and then press Menu Button for selection confirmation.
Generate Main Menu Select by Left and Right Button, and then press Menu Button for selection confirmation.
B.2.4 Geometry Menu – For DVI Input Generate Main Menu Select by Left and Right Button,press Menu Button for selection confirmation.
Generate Main Menu Select by Left and Right Button, and then press Menu Button for selection confirmation.
B.2.6 Language Menu Generate Main Menu Select by Left and Right Button, and then press Menu Button for selection confirmation.
Generate Main Menu Select by Left and Right Button, and then press Menu Button for selection confirmation.
B.2.8 Auto Configuration Menu Generate Main Menu Select by Left and Right Button, and then press Menu Button for selection confirmation.
Generate Main Menu Select by Left and Right Button, and then press Menu Button for selection confirmation. Main Menu -- DISPLAY IN SCREEN Sub-Menu – DISPLAY IN SCREEN Available Key Functions Power Off the LCD Monitor Move the selector to the left Return to the previous menu Select to confirm Move the selector to the right N/A 27 FPM-5151G/5171G/5191G Series User Manual Appendix B OSD Operation Keypad B.2.
B.2.10Memory Recall Menu Generate Main Menu Select by Left and Right Button, , and then press Menu Button for selection confirmation.
Generate Main Menu Select by Left and Right Button, and then press Menu Button for selection confirmation. Main Menu -- DISPLAY IN SCREEN Sub-Menu – DISPLAY IN SCREEN 29 FPM-5151G/5171G/5191G Series User Manual Appendix B OSD Operation Keypad B.2.
B.2.12Hot Keys OSD LOCK/UNLOCK HOT KEYS Press first, and then press for change this setting, Followed this sequence for the button press so that you can have OSD LOCK and UNLOCK setting Enter OSD LOCK MODE – Press HOT KEY, the screen will show this action first – Don’t remove HOT KEY until the screen indicated this task is finished. Enter OSD UNLOCK MODE – Press HOT KEY, the screen will show this action first – Don’t remove the HOT KEY until the screen indicated this task is finished.
Appendix B OSD Operation Keypad 31 FPM-5151G/5171G/5191G Series User Manual
