Datasheet

www.advantech.com/products
Online Download
Dimensions
Panel Cut-out Dimensions: 104 x 140 x 30 mm (4.1" x 5.51" x 1.18")
EKI-2525M/S
EKI-2525M/S
Certification
 Safety EKI-2525M-ST/EKI-2525S: UL/cUL 60950
EKI-2525M: UL/cUL 60950 Class I, Division 2, Groups
A, B, C and D
 EMI FCC Part 15 Subpart B Class A, EN 55022 Class A
 EMs EN 61000-4-2, EN 61000-4-3, EN 61000-4-4
EN 61000-4-5, EN 61000-4-6, EN 61000-4-8
 Shock IEC60068-2-27
 Freefall IEC60068-2-32
 Vibration IEC60068-2-6
Unit: mm
Ordering Information
 EKI-2525M-BE 4-port Ethernet Switch w/ 1-port 100FX Multi-mode
 EKI-2525M-ST-BE 4-port Ethernet Switch w/ 1-port 100FX Multi-mode
(ST type connector)
 EKI-2525S-AE 4-port Ethernet Switch w/ 1-port 100FX Single-mode
140
30
95
45 47 48
140
104
150.20
18
15
47.30
30
