ARK-3399 User Manual 6
1.5 Electrical Specification
1.5.1 Power supply Voltage
Voltage requirement with Adaptor:
9 V
DC
-8 A ~ 34 V
DC
-2.2 A Adaptor
1.5.2 Power supply Current
Supply Current (Maximum), system only, without external device
CPU: Intel® Core Duo L2400 1.66 G, RAM:533MHz 512GB DDR2 SDRAM
1.5.3 RTC Battery
Norminal Voltage: 3.0 V
Nominal discharge capacity: 210 mAh
1.6 Environmental Specification
1.6.1 Operating temperature
System operating temperature
Operating temperature: 0 ~ 55°C (32~131°F) with 0.7m/sec airflow
1.6.2 Relative Humidity
Relative Humidity: At 40°C, 95% Relative Humidity, non-condensing
1.6.3 Vibration during operation
When system is equipped with Compact Flash card only: 5Grms, IEC 60068-2-
64, random, 5~500 Hz, 1 Oct/min., 1hr/axis, x,y,z 3 axes.
When system is equipped with 2.5-inch HDD: 1Grms, IEC 60068-2-64, random,
5~500 Hz, 1 Oct/min., 1hr/axis, x,y,z 3 axes.
1.6.4 Shock during operation
When system is equipped with Compact Flash card only: 50G, IEC 60068-2-27,
half sine, 11 ms duration.
When system is equipped with 2.5-inch: 20G, IEC 60068-2-27, half sine, 11 ms
duration.
Adaptor 19 V
BIOS 1.2 A
WINXP Idle 1.25 A
WINXP
BURN IN TEST
1.42 A
Suspend 0.7 A
Note! Industrial-grade Storage devices supporting at least 75 degree must be
adopted.
