5 ARK-3399 User Manual
Chapter 1 General Introduction
1.4 Mechanical Specification
Figure 1.1 ARK-3399 Dimensions
1.4.1 Dimension
264.5[10.41] x 69.2[2.72] x 137.25[5.4] Unit: mm[Inch]
1.4.2 Weight
2.0 kg (4.4 lb)
137.25
264.50
69.20
6
26.3 72.5
252.5
240
3.5
(3.5)
1.5
6
R2.5
R4
R2
Detailed "A"
SCALE 4 :1
B
Section B-B
B
