ARK-3399 User Manual 4
1.3.1.3 Others
Audio Link
SB: Intel® NH82801GBM chip supports.
Supports HD Codec
Supports Link for Audio and Telephony CODECS
Ear Phone Jack
USB Interface
SB: Intel® NH82801GBM chip supports.
USB host interface with support for 5 USB 2.0 ports
All ports are High-Speed, Full-Speed, and Low-Speed capable
Supports legacy keyboard/mouse software
USB connecter on board: USB conn 4P 180D(M) DIP x 1
USB dual connecter on board: USB conn 8P 90D(M) DIP x 2
Power
Management
SB: Intel® NH82801GBM chip supports.
Supports ACPI 3.0
ACPI Power Management Logic Support
Power connecter: Plug-In block 2P DIP x 1
BIOS
SB: Intel® NH82801GBM chip supports.
Low Pin Count (LPC) interface support
Firmware Hub (FWH) interface support
Phoenix 4M bit Flash BIOS, supports Plug & Play, APM 1.2/ACPI
1.1.
Socket: 32 pin PLCC socket x 1
Serial ports
Super I/O: SMSC SCH3114supports.
2 full function serial ports by SMSC SCH3114.
Support IRQ Sharing among serial ports on XPE
COM1: Supports to RS-232
COM2: Supports to RS-232/422/485 and setting by Jumper
COM connecter: D-SUB CON. 9P 90D(M)DIP x 2
** COM2 RS-485 support Auto flow control.
LAN
LAN Chip: Intel® 82541PI supports
Supports PCI 2.3
Integrated 10/100/1000 transceiver
Fully compliant with IEEE 802.3 compliant
Supports Wake on LAN and remote wake-up
Giga LAN Phone Jack on board: Phone Jack conn 8P 90D DIP x 1
Audio
Audio Codec: Realtek ALC888-GR
Compliant with HD Audio specifications
Supports to 16/20/24-bit DAC and 16/20/24-bit ADC resolution
Ear Phone Jack
LVDS
LVDS Codec: Chrontel CH7308B
Supports 2-CH 24-bit LVDS output up to 1280*1024 48bit
LVDS Connector on board: 3M MDR 26P 90D(F) x 1
Battery backup
Battery support: CR2032
BATTERY 3V/210 mAh with WIRE x 1
