Instructions / Assembly

1
In order to avoid
accidental injury or
damage, DO NOT
remove any awning
arm safety restrains
until instructed to
do so.
Safety instructions and warnings........................................... 2
Package contents and parts .............................................. 3
Tool requirements ...................................................... 4
Product features ....................................................... 4
Installation
Bracket placement reference chart ................................... 5
Determine where to install your awning ............................... 6
Install wall brackets
Standard stud installation ....................................... 7
Masonry installation ............................................ 8
Install ceiling brackets ............................................ 11
Install awning onto brackets ....................................... 12
Ready your awning............................................... 13
Install power cord for electric models ................................ 13
Using remote control ............................................. 13
Operation
Manual model................................................... 14
Electric model .................................................. 14
Adjust awning pitch ............................................. 15
Maintenance.......................................................... 16
Warranty............................................................. 17
TABLE OF CONTENTS
www.advaning.com Toll Free (US): [phone]
SAFETY INSTRUCTIONS
Fig.1
