User's Manual

AWCBX400 UHF Call Box
Owners Manual
Version 12.3.7
Copyright © 2012, Advanced Wireless Communications, All Rights Reserved
AWCBX400 Owner Manual Part Number: 4208-5521-5631
- 5 -
Back Panel Diagram
Figure 2
* Because of internal power storage, unit will remain active for a period of time even after battery is removed.
A. Battery Compartment*
B. Internal Microphone
C. External Microphone Jack (3.5mm)
D. Play Message Button
E. Record Message Button
F. Message Selection Jumpers
G. External Relay Terminals
H. Programming Jack (DB9F)
I. Channel Selection Switches
J. External Power Jacks (7.5 VDC)
K. Radio Audio Control (Factory Set)
L. Internal Antenna (Built into PC Board)
M. Status LED’s (Power, Busy, TX)
N. Internal Speaker for local Voice Message
O. Internal Speaker Mute
P. Flash Programming Jack
Q. Internal Battery Disconnect*
R. Aux Jack (Not Used)
S. Reset Button (Not Used)
Rev 7 PC Board
A
B
C
D
E
F
P
G
H
I
J
O
L
N
M
K
Q
R
S
