18. Initial RC531 Setting For PICC
• Read the Register = {E0 00 00 2F 00}
•
• Update the Registers:
E0 00 00 2F 13 BModeIndex RxAThres106 RxAThres212 RxAThres424 RxAThres848
RxBThres106 RxBThres212 RxBThres424 RxBThres848 RxACtl106 RxACtl212
RxACtl424 RxACtl848 RxBCtl106 RxBCtl212 RxBCtl424 RxBCtl848 CWAConductonce
CWBConductonce
• Response:
E1 00 00 00 13 BModeIndex RxAThres106 RxAThres212 RxAThres424 RxAThres848
RxBThres106 RxBThres212 RxBThres424 RxBThres848 RxACtl106 RxACtl212
RxACtl424 RxACtl848 RxBCtl106 RxBCtl212 RxBCtl424 RxBCtl848 CWAConductonce
CWBConductonce
