RDR_to_PC_NotifySlotChange Format
Offset Field Size Value Description
0 bMessageType 1 50h
1 bmSlotCardState 1
Each slot has 2 bits. The least
significant bit reports the current
state of the slot (0b = no card present,
1b = card present). The most
significant bit reports whether the
slot has changed state since the last
RDR_to_PC_NotifySlotChange
message was sent (0b = no change,
1b = change).
bmSlotCardState Bit Map
Offset Field Description
Bit0 Slot 0 current state PICC slot state
Bit1 Slot 0 changed status PICC slot changed status
Bit2 Slot 1 current state ICC slot state
Bit3 Slot 1 changed status ICC slot changed status
Bit4 Slot 2 current state RFU
Bit5 Slot 2 changed status RFU
Bit6 RFU RFU
Bit7 RFU RFU
