S
TAINLESS STEEL
Fabricated Economy SINKS
One & Two Compartments
FEATURES:
Backsplash has tile edge for ease of installation.
Sink bowls are 3/4" coved corner and meet NSF requirements.
Rolled Rim Edge for additional strength.
Sink Bowls are 14" deep for greater capacity.
NOTE: 15" x 15" bowls are 12" deep.
CONSTRUCTION:
All TIG welded.
Welded areas blended to match adjacent surfaces and to a
satin finish.
Gussets welded to a die-formed reinforced plate.
E-1
MATERIAL:
1 5/8" diameter stainless steel legs with 1" adjustable
stainless steel bullet feet.
Entire unit is 16 gauge 304 stainless steel.
Gussets - stainless steel.
MECHANICAL:
• Supply is 1/2" IPS hot & cold.
• Faucet holes on 8" centers.
• Faucets are not included (see accessories).
• Waste drains are 1 1/2" IPS S/S basket type, located in
center of sink bowl, and are included.
Fabricated Bowls are Welded Together at the Sea ms
K-700
Removable
Side Splashes
Fits Left OR
Right Side
