TRX950;XT90S PROFESSIONAL REMOTE CAR STARTER WITH ALARM SYSTEM & 2-WAY LCD COMMUNICATION OPERATION MANUAL THIS PRODUCT IS DESIGNED FOR PROFESIONAL INSTALLATION ONLY 1
TABLE OF CONTENTS: LCD REMOTE TRANSMITTER: A. REMOTE TRANSMITTER OPERATION… … … … … … … … … … … .… 4 B. BATTERY REPLACEMENT … … … … … … … … … … … … … … … ..… .. 5 C. THE REMOTE LCD ICONS WITH FUNCTION … … … … … ..… ...… ....6 C. PROGRAMMING OF THE LCD REMOTE TRANSMITTER … … … ...7 1. Screen Lamp ON 2. Power Save Mode 3. Clear The Flash Icon and Melody Sound 4. Stop The Melody Sound. 5. Button Lock 6. Vibration / Melody Mode 7. Enable / Disable Bi Sound While Pressing Button: 8. Low Battery Indication. 9.
M. PANIC FUNCTION .… … … … … … … … .… … … … … ..… .… … … .… .… .16 N. TRIGGER THE SYSTEM ..… … ..… … … … … … ..… … … … .… .… … ...17 Clear The Trigger Icons and Melody Sound Stop The Melody Sound Only Noise Abatement Circuit O. ANTI CAR- JACKING .… … … … … … … … … … … … … … … … .… … ...18 Active Anti Car Jacking Passive Anti Car Jacking Trigger The Anti Car Jacking Mode Override The System To Turn Off Anti Car Jacking P. SYSTEM’S TRIGGER CHECK … … … … … … … … .… .… .… ..… .… ...19 Q.
WARNINGS: As with any product that performs automatic functions, there are certain safety precautions that you must practice and be aware of. 1. Keep the transmitter out of children’s reach. 2. Do not leave anyone in the vehicle while running on remote control. 3. Alert servicing personnel that the vehicle can be started automatically. 4. Do not start the vehicle by remote while it’s in an enclosed area or garage. 5. Always apply the parking brake and lock the vehicle as you exit the vehicle. 6.
A. BATTERY REPLACEMENT: This transmitter uses one (1) 3-volt lithium ion battery (#CR2032) that is placed with the (+) side facing upward. To replace the battery, you will need to use a small flat blade screwdriver and a small Philips screwdriver. Remove the small Philips head screw. Then locate the small notch on the lower right side of the transmitter case next to the key ring. Using the flat blade screwdriver, carefully pry the top case from the bottom case. It should snap apart after breaking the seal.
B. THE REMOTE LCD ICONS WITH FUNCTION: Door Lock Your vehicle doors are locked Armed Mode Your vehicle is in armed mode Door Unlock Your vehicle doors are unlocked and the system is Disarmed Valet Mode All the function shall be temporarily on hold. Remote Transmission You are transmitting the signal to control unit Door Open Warning Doors are illegally opened (Zone 3) In – Range Indicator Your are within the remote control range.
C: PROGRAMMING OF THE LCD REMOTE TRANSMITTER: Transmitter Button (1 second) (3 seconds) (5 seconds) - - - (2-second) (2-second) (2-second) Description LCD screen lamp turns on for 5 seconds. Timer Programming Mode. Power Save Mode Clear the Flash Icon and Melody Sound on the LCD Screen Transmitter Press within 3 seconds Button Lock ( disable ) enable / Melody / Vibration ( ) Mode Program Count Down Timer ( ) (10-Minute / 20M / 30 M /1Hour /1.5H / 2.
times within 3 seconds will clear the flash icon and melody sound o n the LCD screen transmitter 4. Stop The Trigger Melody Sound: While triggering the alarm the LCD screen will alert user through melody sound and flashing trigger icon, press any button on the LCD remote transmitter to stop melody sound only. 5. Button Lock: It is useful if you want to disable the transmission function of the remote control temporarily to prevent from any inadvertent pressing of buttons by others.
2. Press the ( ) button again showing next order time on the screen (ie.0: 20), press them again (ie.0: 30)… and so on. 3. Leave the buttons starting count down then icon flashes Note: 1.The count down period is fixed as 10 minutes, 20 minutes, 30 minutes, 1 hour, 1.5 hours and 2 hours maximum. a. When count down timer showing 0:00 means to turn off the timer. b. Press down. button for real time indication when the timer is counting 10. Out Of Range Indication: 1.
1. Clock Setting: Example to AM10:30 1. Press & hold the button for 3 seconds, with two-melody sound and the “Hours” digit flashes for adjusting. 2. Press the AM10:xx or 3. Press the adjusting. button once again then the “Minute” digit flashes for 4. Press the or until AM 10:30 5. button to decrease or increase the “Hour” digit until button to decrease or increase the “Minutes” digit Press the button for 2 seconds with one-melody sound to confirm exit the timer program mode. 2.
“Hours” digit is flashes for adjusting. 3.Press the until 2:xx 4.Press the adjusting. 5. Press the until 2:30 or button to decrease or increase the “Hour” digit button once again then the “Minutes” digit flashes for or button to decrease or increase the “Minute” digit 6. Press the button once again then “ON / OFF” setting icon flashes for alert alarm 7. Press the button to start the count down timer, and the “ON” icon will show on the LCD screen.
Silent Arming / Disarming Ignition in "off" position. Active Anti Car-Jacking Mode Unlock Doors & Disarm System Two Steps Door Unlock & Disarm System Ignition in "on" position press and hold for 2 seconds Trunk Release (Channel 3) Press and Hold for 2 seconds - Passive Arming By-pass While the system Disarmed. Arm System and Hidden Alarm Function Under disarm mode, press within 3 - + + - Press twice within 3 seconds.
1. The XT-85s Standard transmitter: Press the button first, within 3 seconds press and hold the ( ) button for 2 seconds to activate or cancel the button lock function. The “Red LED” will pause flash for few seconds to indicate the remote control transmitter is on “Button Lock” mode when pressing the transmitter button. 2. The 2-way LCD transmitter: Press the button first, within 3 seconds press and hold the ( ) button for 2 seconds to activate or cancel the button lock function.
Light 1. Arming 1 or 3 Chirps 1 Flash 2. Disarming 2 or 4 Chirps 2 or 3 Flashes 3. Trigger Alarming Flashes 4. Passive Starter Disable 5. Panic Alarming 6. Car-Jacking Alarming Flashes Flashes 7. Car Locator 6 Chirps 12 Flashes Slow Flash Locking Disable Turns on for 30 -second Unlocking Slow Flash Disable Fast Flash Disable Disable Flashes Flashes Flashes Locking G. ACTIVE ARMING – LOCK & ARM: 1. Press button on the transmitter. 2.
Arming feature, which allows the security system to arm 30 seconds after the last door is closed. Operation is as follows. 1. Turn the ignition to the “OFF” position and exit the vehicle. 2. After all entrances are closed, the security system LED will flash fast for 30 seconds. If you reopen any door / hood / trunk, the security system LED will stop flashing. It will begin flashing again once all vehicle entrances are closed. 3.
TWO STEPS DOOR UNLOCK: This feature will independently unlock the driver’s door only when disarming the security system. Pushing the will unlock the other doors. button a second time within 3 seconds AUTOMATIC RE-ARM: If this feature is selected, the security system will automatically re-arm itself in 60 seconds after disarming with remote transmitter. Automatic rearm will cancel if any door is opened before the 60 seconds timer has elapsed. J.
K. VALET MODE: (System in Disarm or Valet mode) The valet switch allows you to temporarily bypass all alarm function, eliminating the need to hand your transmitter to parking attendants or garage mechanics. When the system is in valet mode, all alarm functions and remote start functions are bypassed, however the remote panic feature and remote door locks will remain operational.
4. If the button is not pressed, the alarm will automatically stop after 30 seconds. N. TRIGGER THE SYSTEM When armed, your vehicle is protected as follows: 1. Light impact will trigger the warn-away signal. 2. Heavy impacts / Doors open / Hood open / Trunk open / Turning on the ignition key will trigger the programmed sequence. The starter disable relay (if installed) prevents the vehicle’s starter from cranking.
1. Press and hold the trans mitter and button at the same time for 2 seconds while the vehicle’s ignition is ON. The parking lights will turns on for 1.5 seconds to indicate this enter. 2. Once the system is armed, If you are forced from the vehicle, the system will trigger when the door is opened and closed while the ignition is “ON”. PASSIVE ANTI CAR- JACKING: It operate as below: 1. Turn the ignition switch to the “ON” position; the system will arm. 2.
Q. SYSTEM’S STATUS CHECK When you want to check the system’s present status through the LCD screen, Press the transmitter button twice, within 3 seconds press It responds with one melody sound. (C) button. R. DRIVER PAGING It is useful the event that someone wants to page the driver of the parked vehicle.
Note: Turn on the ignition switch or arm the alarm will turn off the dome light. T. IGNITION CONTROL DOOR LOCK/UNLOCK. If the vehicles door locks have been interfaced to the security system, the system will automatically lock the vehicle's doors when the ignition is turned “ON” and /or unlock the vehicle’s doors when the ignition is turned “OFF”. U. TRUNK RELEASE (CHANNEL 3) OUTPUT. Press and hold button on the transmitter for two seconds to remote control the trunk release or other electric devices. V.
Your 5-button remote transmitter can be utilized to control a second vehicle security system, To program the remote control transmitter to a second vehicle, follow the instructions for Transmitter programming. Programming the Transmitter to 2 nd Car Enter: 1. Turn the ignition key ON 3 times. (Finishing in the ON position) 2. Press valet switch 2 times, holding in on the 2nd push, you will hear a long siren chirp. (Release the valet switch) 3. Press the shift button of the Car 2 transmitter.
. REMOTE START OPERATION: A. TO REMOTE START THE VEHICLE: When you want to start your vehicle, Activate Remote Start 1. Press button once on the transmitter. 2. The parking light will activate to indicate the remote start received the signal. 3. The engine will start approximately 5 seconds. 4. Once the engine is running, after couple seconds the parking light will turn on again and climate controls will activate and adjust the vehicles interior temperature to your preset setting.
to exit and lock the vehicle for short periods of time, but would like to leave the motor running and the climate control on. 1.Before turning off the engine, press the button twice on the transmitter and the LED indicator will flash 3 times to confirm enter. 2.Turn the ignition key to OFF position. (The engine will stay running.) 3.The engine will run until the pre-programmed time elapsed or shutdown input is received.
Daily Timer Start: The feature is very useful for the driver who wants to run the vehicle punctually at the same time next morning. Before set-up of the “Daily Timer Start”, you should set you time for engine start.( see Timer Setting / Timer set-up for “Daily Timer Start, page 16) ENTER: 1. Press the button once to remote start the vehicle. 2. Immediately depress the button once, within 2 seconds 3-a.
H. SHUT-DOWN INPUT FOR REMOTE STARTER: If any of the following conditions exist while the system is operating, the engine will not start or will shut down immediately: 1. The hood is opened. 2. The brake pedal is pressed. 3. Engine is over-revved. {“Tachometer checking type” only} 4. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed. 5. Press button once on the remote transmitter under remote start mode. 6. Move the optional remote start enable toggle switch to OFF position.
LIMITED LIFETIME WARRANTY PROVISIONS ( U.S. ,Continental U.S. and Canada Only) 1. Auto Page, Inc. WARRANTS that this new unit has been thoroughly in spected and tested at the factory prior to delivery.
5. Any unexpired WARRANTY shall be applicable to equipment and parts in the possession of the original purchaser only. 6. THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. 7.
City, State, Zip Code City, State, Zip Code ___________________________ ________________________________ Telephone Number Dealer’s Telephone Number ___________________________ ________________________________ Year / Make / Model of Vehicle Date of Installation / Purchase ________________________________ Dealer’s Signature “Proof of Purchase” which includes the store name and date of purchase must accompany all warranty returns.
960 Knox Street Unit B Torrance, California 90502 Main Office: 310-323-1800 Customer Service: 800-262-2527 Ext. 462 www.autopageusa.
