Section 5, User Interface - Menu Descriptions
61179605L5-5B 5-61
TFTP Firmware Download Screen
The TFTP Firmware Download screen (see Figure 5-43) is used to download code stored from
a computer to the Total Access 1240 through a TFTP server.
Figure 5-43. TFTP Firmware Download Screen
The TFTP Firmware Download screen fields are shown in Table 5-44.
Table 5-44. TFTP Firmware Download Screen Fields
Field Description
TFTP Server This field displays the IP address of the TFTP server. The TFTP
IP address must be configured prior to attempting a TFTP
download.
Get Code For This field displays the module that will be upgraded.
TFTP Filename This field displays the TFTP filename that will be used to
upgrade the module shown in the Get Code For field. The TFTP
filename must be known and must match the part number.
Total Access 1240 - IPoE Fed
Unacknowledged Alarms: None
TFTP Firmware Download
TFTP Server: 10.200.200.218
Get Code for: 1179605L5_A_*** Flash A
TFTP Filename:
Error Status:
Update progress:
Press Space bar to enter TFTP address
