3.5 BP-8005 Layout, Connectors and Jumpers
The BP-8005 backplane provides 1 system slot and 4 available
PCI peripheral slots. These PCI slots are for 32-bit and 33 MHz
PCI devices.
Figure 3-7:
CN3
JP1
JP3
CN2
CN4 CN1
JP2
PCI4 PCI3 PCI2 PCI1 SYSTEM
BP-8005 Backplane Layout
NOTE:
NOTE:
The system slot is occupied by a pre-installed PCI-8565,
please DO NOT install a CPU controller in this slot.
