User manual

ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 6 ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 7
Screw one clamp via a M12 screw and nut to the included
bracket. Attach the bracket using the omega locks to the
bottom of the Focus Spot Two. Attach and pull the safety-cable
through one of the safety holes located on the bottom base and
over the trussing system or a safe xation spot. Insert the end
in the carabine and tighten the safety screw.
NOTICE: The suitable enviromental temperature for this light-
ing xture is between -25˚ C to 45˚ C. Do not place this lighting
xture in an enviroment where the temperatures are under or
above the temperatures stated above. This will allow the xture
to run at its best and help prolong the xture life.
Focus Spot Two Mounting Focus Spot Two CAD Drawing
237mm/9.33”
385mm/15.15”
173mm/6.81”
Clamp
Suspender
Screew
