455883-B21-AO
HP, 10GBASE-SR SFP+ MMF
850NM 300M REACH LC
Parameter
Conditions
Symbol
Min
Typ
Max
Units
Supported Data Rate
VID
1
10.3125
11.3
Gbd
Reference Differential Input
Impedance
Zd
100
Ω
Input AC Common Mode
Input Voltage
0
25
mV
(RMS)
Differential Input Voltage
Swing
VID
150
900
mV
0.01 –
3.9GHz
SDD11
-10
dB
Differential Input S-
parameter
3.9 –
11.1GHz
1)
1)
dB
Differential to Common
Mode Conversion 2)
0.01 –
11.1Ghz
SCD11
-10
dB
Total Jitter
TJ
0.28
UI(p-p)
Data Dependant Jitter
DDJ
0.1
UI(p-p)
Uncorrelated Jitter
UJ
0.023
RMS
X1
0.14
UI
Eye Mask
See SFP+ MSA
X2
0.35
UI
SFI Module Receiver Output Characteristics
Parameter
Conditions
Symbol
Min
Typ
Max
Units
Supported Data Rate
1
10.312
5
11.3
Gbd
Reference Differential
Output Impedance
Zd
100
Ω
Termination Mismatch
ΔZd
5
%
Output AC Common Mode
Output Voltage
15
mV
(RMS)
Differential Output Amplitude
RLoad=100Ohm ,
Differential
VOSPP
350
650
800
mV
Output Rise and Fall time
20% to 80%
tRH, tFH
24
35
ps
0.01 – 3.9GHz
-10
dB
Differential Input S-
parameter
3.9 – 11.1GHz
SDD22
1)
dB
0.01 – 6.5Ghz
-7
dB
Common Mode Output
Return Loss2)
6.5 – 11.1Ghz
SCC22
-3
dB
