B
SYSTEM SPECIFICATIONS AND
COMPLIANCE
Table A-1 System Specifications and Compliance
Physical Dimensions ■ 15.75” H x 17.1” W x 15.9” D
■ Weight: Approx 100 lbs (fully populated chassis) 28
lbs (chassis only)
Physical Interface
Modules
■ 1x4 DOCSIS Module— 1 downstream channel, 4
upstream channels
■ 1x4 DOCSIS SpectraFlow Module— 1 downstream
channel, 4 upstream channels
■ 1x6 DOCSIS SpectraFlow Module with Spectrum
Management — 2 downstream channels, 6 upstream
channels
■ 1x4 EuroDOCSIS Module — 1 downstream channel, 4
upstream channels
■ 1x4 EuroDOCSIS SpectraFlow Module — 1
downstream channel, 4 upstream channels
■ 1x4 EuroDOCSIS SpectraFlow Module with Spectrum
Management — 2 downstream channels, 4 upstream
channels
■ Octal 10/100BASE-TX Ethernet SpectraFlow Module
■ Gigabit Ethernet SpectraFlow Module
■ Packet Over SONET (POS) SpectraFlow Modules
- POS OC-3
- POS OC-12
Downstream CMTS RF
Interface
■ DOCSIS 1.0/1.1
■ Frequency range: 93 MHz to 855 MHz settable in 250
kHz increments (STD, IRC, HRC)
■ Modulation: 64 or 256 QAM
■ Information rate: 27 or 38 Mbps
