Cabling for System Fault Reporting 121
To receive fault signals, you must attach the devices that you want to report
on to the Alarms In DB-15 connector using one of these ADC-provided
cables:
Different power supplies may utilize different connectors. Contact ADC
Customer Support for details.
Use the following procedure to cable the system for fault reporting:
1. If you haven’t already done so, review “Electrical Safety Guidelines and
Precautions” on page 59.
2. Do one of the following:
■ If you are cabling to a fan tray only, use the 2-way cable and attach
the DB-9 connector on the cable to the DB-9 port on the rear panel of
the fan tray. Then connect the DB-15 connector on the other end of
the cable to the Alarms In port on the rear of the chassis. Refer to
Figure 5-20.
or
■ If you are cabling to a single power supply, or both a fan tray and
power supply, use the 3-way cable and attach the DB-9 connector on
the cable to the DB-9 port on the rear panel of the fan tray and the
DB-25 connector to the power supply. Then connect the DB-15
connector on the other end of the cable to the Alarms In port on the
rear of the chassis. Refer to Figure 5-21.
2-way cable - This cable consists of these connectors:
■ DB-15 for connection to the chassis.
■ DB-9 for connection to the fan tray.
3-way cable - This cable consists of these connectors:
■ DB-15 for connection to the chassis.
■ DB-9 for connection to the fan tray.
■ DB-25 for connection to a single power supply.
