Configuring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 5-23
Setting the Loopback Timeout
The loopback timeout determines the amount of time before a loopback clears
automatically. Choose one of the following:
• 20 minutes
• 60 minutes
• 120 minutes
• None (disables the loopback timeout)
1 Open the Loopback Settings menu.
2 Type then press . The Loopback Settings menu shows the new
Loopback Timeout setting. Repeat this step until the desired setting
displays.
If you set the loopback timeout to NONE, a loopback runs until
you clear it manually or turn the unit off.
7 ENTER
