Configuring with an ASCII Terminal
5-22 Campus-REX RS Interface Card User Manual
2 Type then press . The Loopback Settings Menu displays.
Initiating a Loopback
To initiate a loopback condition:
1 Open the Loopback Settings menu.
2 Type the number that corresponds to the desired loopback then press
. The Loopback Settings menu displays the new loopback status.
Clearing a Loopback
To clear a loopback condition:
1 Open the Loopback Settings menu.
2 Type then press . The system disables the loopback and the
Loopback Settings menu displays.
1 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:29:44
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
LOOPBACK SETTINGS
ACTIVE LOOPBACK: None
1) Local Data Port toward Local Data Port N/A
2) Remote Data Port toward Local Data Port N/A
3) Local Data Port toward Remote Data Port
4) Remote Data Port toward Remote Data Port
5) Terminate Loopbacks
6) Loopback Timeout (min): None (20, 60, 120, None)
WARNING: Any loopback will remove data link from service.
(R)eturn (M)ain Menu
ENTER CHOICE>
ENTER
6 ENTER
CAD1069i5.book Page 22 Thursday, May 30, 2002 7:32 AM
