Configuring with an ASCII Terminal
Campus-REX RS Interface Card User Manual 5-21
• The Remote to Remote loopback tests the remote data port.
• The Local to Remote loopback tests the remote data port, the entire data
path inside the remote Campus unit, the HDSL line, the HDSL
transceivers of both units, and most of the internal data path inside the
local unit. This loopback does not test the local data port drivers and
receivers.
Once a loopback condition has been initiated, it remains in effect until
cleared. You may also set a loopback timeout to clear the loopback
automatically after a set period of time has elapsed.
All loopback options are accessed through the Loopback Settings menu. To
open this menu:
1 From the Main Menu, type then press . The Diagnostics Menu
displays.
4 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:29:35
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
DIAGNOSTICS MENU
1) LOOPBACK SETTINGS MENU
2) DOWNLOAD MODE
(R)eturn
ENTER CHOICE>
