Configuring with an ASCII Terminal
5-18 Campus-REX RS Interface Card User Manual
2 Type then press . The System Parameters menu displays.
3 Continue with the following sections to set the desired options.
Setting the Time and Date
The Campus unit uses the time and date to record system events, such as
alarms. To set the time and date:
1 From the System Parameters menu, type then press . The
system prompts you to enter the time.
2 Type the correct hour, in 24-hour format, a colon (:), and the minute then
press . The system displays the System Parameters menu with the
correct time.
3 Type then press . The system prompts you to enter the date.
4 Type the number of the day, the number of the month, and the four-digit
year, separated by slashes (/) then press . The system displays the
System Parameters menu with the correct date.
1 ENTER
May 3, 1999 ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx 13:18:50
Local Unit ID: Campus-REX Unit #34 Local I/F: REX
Remote Unit ID: Campus-REX Unit #12 Remote I/F: REX
Circuit ID: Network Extension Circuit 5001
SYSTEM PARAMETERS
1) Change System Time
2) Change System Date
3) Change Unit ID
4) Change Circuit ID
5) Change Password
6) HDSL ES Alarm Threshold: Disabled (Disabled, 17, 170)
7) HDSL Margin Alarm Threshold: Disabled
8) Local Data Port LOS Alarm: Disabled (Disabled, Enabled)
9) Remote Data Port LOS Alarm: Disabled (Disabled, Enabled)
10) RESET TO FACTORY DEFAULT
(R)eturn (M)ain Menu
ENTER CHOICE>
1
ENTER
ENTER
2 ENTER
ENTER
